GE IC755ACC15MNT 电源和串行端口连接器

【产品详情】

 IC755ACC15MNT套件是 GE Fanuc 的 Quickpanel 配件套件。IC755ACC15MNT套件包含电源和串行端口连接器以及安装夹。

GE Fanuc IC755ACC15MNT套件是一个 Quickpanel 附件套件，其中包含替换安装夹、串行端口连接器和电源连接器。IC755ACC15MNT套件与配备 15 英寸显示屏的 Quickpanel+ 设备兼容。Quickpanel 和 Quickpanel+ 单元是 ARM 微处理器驱动的工业操作终端，运行 Microsoft Windows 的 Embedded Compact 7 版本。这些装置上的电源连接器是 Tyco Electronics 284510-3 连接器，可用于 +24 伏直流或 +12 伏直流输入。RS-232 串行端口连接器是 Tyco Electronics 284510-5 连接器，可与额定华氏度为 30 的 AWG 14 至 AWG 167 电线一起使用 0 华氏度。安装螺钉的推荐扭矩为 3.755 N-m。 反复重新拧紧用于单元安装的夹子会导致垫圈退化，应避免这种情况。IC15ACC<>MNT套件可用于更换缺失或损坏的部件。

使用IC755ACC15MNT备件套件的 Quickpanel+ 终端上的触摸屏显示基于投射电容式触摸技术，支持 2 点多点触控。15 英寸 Quickpanel+ 单元配备 15 英寸 TFT LCD 屏幕，分辨率为 1024 x 768,65 色，亮度为 536 尼特。通信选项包括两个带 RJ-310 接口的 10/100BaseT 以太网、一个 RS-45 端口、一个 RS-232/232 接口和 485 个 USB 2.2 接口，可在 0.5 安培时提供 0 伏电源。为音频输出提供一条线路。这些装置的抗噪等级为 5 伏峰峰值，脉冲持续时间为 1500 微秒，上升时间为 1 纳秒。Quickpanel 装置的额定功耗为 1 瓦。30 伏直流电时电流消耗为 1.25 安培，24 伏直流电时电流消耗为 2.5 安培。

GE IC755ACC15MNT 电源和串行端口连接器

【英文介绍】

The IC755ACC15MNT kit is GE Fanuc's Quickpanel accessory kit. The IC755ACC15MNT kit includes power and serial port connectors and mounting clips.

The GE Fanuc IC755ACC15MNT kit is a Quickpanel attachment kit that includes a replacement mounting clip, a serial port connector, and a power connector. The IC755ACC15MNT kit is compatible with Quickpanel+ devices with a 15-inch display. Quickpanel and Quickpanel+ units are ARM microprocessor-powered industrial operating terminals running Embedded Compact 7 version of Microsoft Windows. The power connector on these units is the Tyco Electronics 284510-3 connector, which can be used for +24 volts DC or +12 volts DC input. The RS-232 serial port connector is a Tyco Electronics 284510-5 connector that can be used with AWG 14 to AWG 167 wires rated at 30 degrees Fahrenheit for 0 degrees Fahrenheit. The recommended torque for mounting screws is 3.755 N-m. Repeated retightening of clamps used for unit mounting can cause gasket degradation and should be avoided. The IC15ACC<>MNT kit can be used to replace missing or damaged parts.

The touch screen display on the Quickpanel+ terminal using the IC755ACC15MNT spare parts kit is based on projected capacitive touch technology and supports 2-point multi-touch. The 15-inch Quickpanel+ unit features a 15-inch TFT LCD screen with a resolution of 1024 x 768,65 colors and a brightness of 536 nits. Communication options include two 10/100BaseT Ethernet with RJ-310 ports, one RS-45 port, one RS-232/232 port, and 485 USB 2.2 ports that provide 0 volts of power at 0.5 amps. Provide a line for audio output. These units have an anti-noise rating of 5 volts peak peak value, pulse duration of 1500 microseconds, and rise time of 1 nanosecond. Quickpanel devices are rated for power consumption of 1 watt. Current consumption is 1.25 amps at 30 volts DC and 2.5 amps at 24 volts DC.

GE IC755ACC15MNT 电源和串行端口连接器
