GE Fanuc IC697MDL341 离散输出模块 自动键控

【产品详情】

技术规格

额定电压： 120/240 伏交流电

输出数量： 12 个单独隔离

输出电流： 每点 2 安培，每个模块 16 安培

所需电流： 0.25 安培

频率： 47 至 63 赫兹

直流电源： 不

IC697MDL341输出模块是GE Fanuc的产品，属于GE 90-70系列。它在 120 至 240 伏交流电的额定电压下运行，并具有 12 个隔离点，可确保在交流电源上使用不同的相位。该模块每个输出点具有 2 安培的电流容量以及 10 倍额定电流的高浪涌容量，因此允许显着范围的白炽灯和电感负载。每个输出都与额定电流为 3.15 安培的可更换保险丝熔断。GE Fanuc IC697MDL341输出模块具有 LED 指示灯，可显示电路逻辑侧每个输出点的开/关状态。此外，该模块还有一个 LED 指示灯，用于显示模块上不同保险丝的状态。当任何保险丝熔断时，LED 指示灯将亮起以显示它。

IC697MDL341输出模块自动键控，以确保在地面上使用相同类型的模块进行正确更换。操作员可以在不使用 DIP 开关和跳线的情况下配置输入和输出基准。GE Fanuc IC697MDL341输出模块与各种负载设备兼容并与之配合使用，例如指示器、螺线管和电机启动器。每个点的额定电流为 2 安培，适用于每个点的当前长期能力。该模块内的整体散热将总电流限制为 16 安培。输出可以通过超过持续电流额定值来快速执行浪涌电流。浪涌会根据此模块的额定电流以及设备通电或占空比时的百分比重复出现。

GE Fanuc IC697MDL341 离散输出模块 自动键控

【英文介绍】

Technical specification

Rated voltage: 120/240 volts AC

Number of outputs: 12 individually isolated

Output current: 2 amps per point, 16 amps per module

Required current: 0.25 amps

Frequency: 47 to 63 Hz

Dc power supply: No

The IC697MDL341 output module is a product of GE Fanuc and belongs to the GE 90-70 series. It operates at a rated voltage of 120 to 240 volts AC and has 12 isolation points that ensure different phases are used on the AC power supply. The module has a current capacity of 2 amps per output point as well as a high surge capacity of 10 times the rated current, thus allowing a significant range of incandescent and inductive loads. Each output is blown with a replaceable fuse rated at 3.15 amps. The GE Fanuc IC697MDL341 output module has an LED indicator that shows the on/off status of each output point on the logic side of the circuit. In addition, the module has an LED indicator to show the status of different fuses on the module. When any fuse is blown, the LED indicator light will light up to show it.

The IC697MDL341 output module is automatically keyed to ensure correct replacement on the ground using the same type of module. The operator can configure input and output benchmarks without the use of DIP switches and jumpers. The GE Fanuc IC697MDL341 output module is compatible with and works with a wide range of load devices, such as indicators, solenids and motor starters. Each point is rated at 2 amps for the current long-term capacity of each point. The overall heat dissipation within this module limits the total current to 16 amps. The output can perform the surge current quickly by exceeding the sustained current rating. The surge repeats according to the rated current of this module and the percentage of the device when it is powered on or duty cycle.
