GE Fanuc IC697CPU731 可编程逻辑控制器系统连接

【产品详情】

GE Fanuc IC697CPU731 CPU 是 GE 90-70 系列组件产品线的一部分，这些组件可作为 PLC 或可编程逻辑控制器系统连接。它是一个单插槽 CPU，这意味着它只需要安装在 PLC 底板的 1 个插槽中，即可牢固地固定到位并正常运行。IC697CPU731 CPU 的目的是处理它从多达 512 个输入和输出接收的数据，这些输入和输出可以以任何组合方式排列。它还可以支持 8000 个模拟 I/O。此 CPU 使用的微处理器是额定频率为 80 Mhz 的 186C12 微处理器。IC697CPU731 CPU 中的数据和程序存储器可以由用户配置。

技术规格

模块类型： 中央处理器

插槽数量： 1 （单插槽）

所需电流： 1.0 安培

点数： 512 个输入和输出（任意混音）

串口： 一

支持： IC660/IC661 I/O 和 IC697 I/O

GE Fanuc 90-70 系列 IC697CPU731 CPU 可以通过 DOS 或基于 Windows 的软件进行编程，以实时控制物料搬运系统和应用过程。它使用PLC的背板与连接的I/O模块以及各种智能选件模块（如果PLC有）进行通信。一些兼容的智能选件模块包括多个通信模块和协处理器模块，以及IC697 LAN接口模块、IC697分立和模拟I/O模块。模块的操作可以通过一个开关来控制，该开关可以设置为1个位置中的3个，也可以通过连接的编程器和编程软件进行远程控制。当 PLC 断电时，必须安装 IC697CPU731 CPU，并且其电池需要连接到其中一个电池连接器。

GE Fanuc IC697CPU731 可编程逻辑控制器系统连接

【英文介绍】

The GE Fanuc IC697CPU731 CPU is part of the GE 90-70 series product line of components that can be connected as PLC or programmable logic controller systems. It is a single slot CPU, which means it only needs to be installed in 1 slot of the PLC baseboard to be firmly fixed in place and operate properly. The IC697CPU731 CPU is designed to process the data it receives from up to 512 inputs and outputs that can be arranged in any combination. It can also support 8,000 analog I/ OS. The microprocessor used by this CPU is a 186C12 microprocessor rated at 80 Mhz. Data and program storage in the IC697CPU731 CPU can be configured by the user.

Technical specification

Module type: CPU

Number of slots: 1 (single slot)

Required current: 1.0 amp

Count: 512 inputs and outputs (any mix)

Serial port: one

Support: IC660/IC661 I/O and IC697 I/O

The GE Fanuc 90-70 Series IC697CPU731 CPU can be programmed via DOS or Windows-based software to control material handling systems and application processes in real time. It uses the backplane of the PLC to communicate with the connected I/O modules as well as various smart option modules (if the PLC has one). Some compatible smart option modules include multiple communication modules and coprocessor modules, as well as IC697 LAN interface modules, IC697 discrete and analog I/O modules. The operation of the module can be controlled by a switch, which can be set to 3 in 1 position, or remotely controlled by a connected programmer and programming software. When the PLC is powered off, the IC697CPU731 CPU must be installed, and its battery needs to be connected to one of the battery connectors.
