IC697CMM742 以太网接口   有三个网络端口

【产品详情】

产品描述

IC697CMM742模块是GE为90-70系列Type 2设计的以太网接口。IC697CMM742模块配有三个网络端口，用于在IC697 PLC和以太网LAN之间建立连接。以太网接口模块的网络端口是标准配置，设计有 15 个引脚，可选择 10Base5、10Base2、10BaseT、10BaseF 或 10Broad36 介质，并带有用户提供的 802.3 兼容收发器。

IC697CMM742 以太网接口（2 型）还包括预加载的固件，便于安装;此外，固件易于升级和无限期维护。该接口通过配置/基于逻辑的以太网全局数据提供数据交换，通过 SRTP 提供 TCP/IP 通信，提供完整的 PLC 编程/配置以及全面的站点管理/诊断工具。

IC697CMM742 以太网接口配有四个 LED：MODULE OK、LAN ONLINE、SERIAL ACTIVE 和 STATUS OK。如果诊断成功，MODULE OK LED 将亮起。如果诊断失败，LED 将保持熄灭状态。 诊断期间闪烁是正常的和/或表示特殊操作条件。当连接到网络并准备就绪时，LAN ONLINE LED 将亮起。如果出现中断或故障，它将发出 OFF。闪烁是正常的，表示正在传输数据。SERIAL ACTIVE 将在不活动期间显示 OFF，并在数据传输期间闪烁。STATUS OK 为 ON 表示正常运行。OFF 表示需要用户注意的事件，同样，闪烁是正常的。

GE Fanuc IC697CMM742接口是为 GE 系列 90-70 PLC 系统制造的以太网接口设备。该以太网接口带有 3 个网络端口，可用于连接其主机 PLC 和以太网 LAN。这 3 个端口分别是 AUI 网口、10BaseT 网口和 10Base2 网口。AUI网口是15个引脚的标准网口，可以通过收发器连接不同的设备。IC697CMM742以太网接口自带预装固件，使接口易于安装，固件本身可通过PC轻松升级，PC可通过RS-485串口连接到接口。界面上有一个按钮，可用于重新启动它。

GE Fanuc 系列 90-70 IC697CMM742以太网接口旨在为其主机 PLC 系统提供 TCP/IP 通信。它通过插入 PLC CPU 机架的 1 个插槽，然后配置了 IC641 PLC 编程软件，安装在托管它的 PLC 系统中。多达 4 个以太网接口（如 IC697CMM742 以太网接口）可以安装在同一个 PLC CPU 机架中。接口一次只能使用其 1 个网络端口中的 3 个，并且会自动选择在特定时间使用哪个网络端口。IC697CMM742 以太网接口有 4 个 LED，用于接口状态更新，包括 MODULE OK、LED、LAN ONLINE、LED、串行活动、LED 和状态 LED。

IC697CMM742 以太网接口   有三个网络端口

【英文介绍】

Product description

The IC697CMM742 module is GE's Ethernet interface for the 90-70 series Type 2. The IC697CMM742 module is equipped with three network ports for the connection between the IC697 PLC and the Ethernet LAN. The Ethernet interface module's network port is standard, designed with 15 pins, a choice of 10Base5, 10Base2, 10BaseT, 10BaseF, or 10Broad36 media, and comes with a user-supplied 802.3-compatible transceiver.

The IC697CMM742 Ethernet interface (Type 2) also includes pre-loaded firmware for easy installation; In addition, the firmware is easy to upgrade and maintained indefinitely. This interface provides data exchange via configuration/logic-based Ethernet global data, TCP/IP communication via SRTP, complete PLC programming/configuration, and comprehensive site management/diagnostic tools.

The IC697CMM742 Ethernet interface is equipped with four leds: MODULE OK, LAN ONLINE, SERIAL ACTIVE and STATUS OK. If the diagnosis is successful, the MODULE OK LED will light up. If the diagnosis fails, the LED will remain off. Flickering during diagnosis is normal and/or indicates special operating conditions. When connected to the network and ready, the LAN ONLINE LED will light up. If there is an interruption or failure, it will issue an OFF. If the indicator blinks normally, data is being transmitted. SERIAL ACTIVE will show OFF during periods of inactivity and blink during data transfer. STATUS OK indicates normal operation if the value is ON. OFF indicates an event that requires the user's attention, and again, blinking is normal.

The GE Fanuc IC697CMM742 interface is an Ethernet interface device manufactured for GE series 90-70 PLC systems. The Ethernet interface comes with 3 network ports that can be used to connect its host PLC and Ethernet LAN. The three ports are AUI, 10BaseT, and 10Base2. The AUI network port is a 15-pin standard network port that connects different devices via a transceiver. The IC697CMM742 Ethernet interface comes with pre-installed firmware, which makes the interface easy to install, and the firmware itself can be easily upgraded from a PC, which can be connected to the interface via the RS-485 serial port. There is a button on the interface that can be used to restart it.

The GE Fanuc Series 90-70 IC697CMM742 Ethernet interface is designed to provide TCP/IP communication for its host PLC systems. It is installed in the PLC system hosting it by plugging into a slot in the PLC CPU rack and then configuring the IC641 PLC programming software. Up to four Ethernet interfaces, such as the IC697CMM742 Ethernet interface, can be installed in the same PLC CPU rack. An interface can only use 3 of its 1 network ports at a time, and automatically selects which network port to use at a given time. The IC697CMM742 Ethernet interface has four leds for interface status updates, including MODULE OK, LED, LAN ONLINE, LED, Serial activity, LED, and Status LED.
