GE Fanuc IC697CGR935 单插槽控制器 用作控制器

【产品详情】

产品描述

IC697CGR935模块是GE Fanuc系列中的单插槽控制器，允许CPU冗余应用必须进行波动点计算。冗余系统中的IC697CGR935模块用作控制器。使用IC697CGR935时需要注意两种控制方法。在 GHS 过程中，每个同步 PLC 中使用多个带有一个冗余控制器的单总线网络。使用 GDB 工艺时，每个同步 PLC 中使用多个 I/O 网络和单总线或双总线。每种控制方法都可以轻松激活和使用。在IC697CGR935模块中，存储器板提供数据，程序存储器包含在模块中。IC697CGR935可以远程操作，也可以通过三位 RUN/STOP 开关操作。位于模块前面的是 LED，用于指定 CPU 的状态。

在未参考相应的可编程控制器安装和热备用 CPU 冗余手册之前，不应尝试安装 IC97CGR935 模块。电池应连接到模块的电池连接器之一。按键开关应定位为 MEMORY PROTECT OFF，并且不应有机架电源。将模块安装在机架 1 的插槽 0 中后，电源将打开。顶部 LED 应闪烁，表示 IC697CGR935 模块已通电。有效完成诊断后，左上角的 LED 保持亮起，而第二个和第三个 LED 将熄灭。第四个 LED 的 MEMORY PROTECT LED 熄灭，因为按键开关处于关闭位置。现在已准备好对 CPU 进行编程。无论按键的位置如何，都可以对 CPU 进行编程。确认程序后，拨动开关可以定位在适当的操作模式下。

技术规格

模块类型： 单插槽 CPU

工作温度： 0 至 60 摄氏度（32 至 140 华氏度）

电池保质期： 在 5 摄氏度（20 华氏度）下 68 年

输入和输出： 每个 12K（任意混音）

串口： 3

所需电流： 3.1 安培标称值

GE Fanuc IC697CGR935 CPU 是配备 80486DX4 处理器的 CPU。它与 GE 90-30 系列和 90-70 系列 PLC 系统完全兼容。它能够进行浮点计算，并广泛用于工业应用。CPU 使用带有 MS-DOS 或 Windows 编程软件的个人计算机进行编程。它以 5 伏的电源电压运行。它的额定电流为 3.1 安培。CPU 使用 1 MB 的 CMOS RAM 进行处理。内存由电池备份。IC697CGR935可编程 CPU 配备 2 个端口，分别称为端口 1 和 2。AS693232SNP电缆可以连接到任一端口。

IC697CGR935 CPU 的正面有 LED 状态指示灯，可针对不同事件呈绿色常亮。如果电缆连接到任一端口，LED 会亮起。左中间的 LED 指示处理器的功能，底部的 LED 显示 I/O 活动。除了这些 LED 之外，还包括一个与 LED 相对应的 3 位开关。在顶部位置，开关允许所有功能。如果开关切换到中间位置，所有输出将被禁用，当切换到底部位置时，开关将导致 CPU 退出 RUN 模式。IC697CGR935 CPU 只能在温度范围在 0 到 50 摄氏度之间的位置运行。对于超过 50 摄氏度的温度，需要采用强制冷却方法。IC697CGR935 CPU 配备了一个 RJ 45 端口，用于网络和通信连接。

 GE Fanuc IC697CGR935 单插槽控制器 用作控制器

【英文介绍】

Product description

The IC697CGR935 module is a single-slot controller in the GE Fanuc family that allows CPU redundancy applications to perform necessary wave point calculations. The IC697CGR935 module in the redundant system functions as the controller. There are two control methods to be aware of when using IC697CGR935. In the GHS process, multiple single-bus networks with one redundant controller are used in each synchronous PLC. When using the GDB process, multiple I/O networks and single or dual buses are used in each synchronous PLC. Each control method can be easily activated and used. In the IC697CGR935 module, the memory board provides the data and the program memory is contained in the module. The IC697CGR935 can be operated remotely or with a three-digit RUN/STOP switch. Located in front of the module is the LED, which specifies the state of the CPU.

You should not attempt to install the IC97CGR935 module without referring to the appropriate Programmable controller installation and Hot standby CPU redundancy manual. The battery should be connected to one of the battery connectors of the module. The key switch should be positioned to MEMORY PROTECT OFF and there should be no rack power supply. After the module is installed in slot 0 of rack 1, the power will be turned on. The LED at the top should flash, indicating that the IC697CGR935 module is powered on. After the diagnosis is effectively completed, the LED in the upper left corner remains lit, while the second and third leds are extinguished. The MEMORY PROTECT LED of the fourth LED is off because the key switch is in the off position. You are now ready to program the CPU. The CPU can be programmed regardless of the position of the keys. After confirming the program, toggle the switch can be positioned in the appropriate operating mode.

Technical specification

Module type: single-socket CPU

Operating temperature: 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)

Battery life: 68 years at 5 degrees Celsius (20 degrees Fahrenheit)

Input and output: 12K each (any mix)

Serial port: 3

Required current: 3.1 amps nominal value

The GE Fanuc IC697CGR935 CPU is a CPU with an 80486DX4 processor. It is fully compatible with GE 90-30 series and 90-70 series PLC systems. It is capable of performing floating-point calculations and is widely used in industrial applications. The CPU is programmed using a personal computer with MS-DOS or Windows programming software. It operates at a supply voltage of 5 volts. It has a rated current of 3.1 amps. The CPU uses 1 MB of CMOS RAM for processing. The memory is backed up by the battery. The IC697CGR935 programmable CPU is equipped with two ports, called ports 1 and 2. The AS693232SNP cable can be connected to either port.

The front of the IC697CGR935 CPU has a LED status indicator, which can be green on for different events. If the cable is connected to either port, the LED lights up. The left center LED indicates the processor's capabilities, and the bottom LED shows I/O activity. In addition to these leds, a 3-bit switch corresponding to the LED is also included. In the top position, the switch allows all functions. If the switch switches to the middle position, all output will be disabled, and when switched to the bottom position, the switch will cause the CPU to exit RUN mode. The IC697CGR935 CPU can only operate in a temperature range between 0 and 50 degrees Celsius. For temperatures above 50 degrees Celsius, a forced cooling method is required. The IC697CGR935 CPU is equipped with an RJ 45 port for networking and communication connections.

 GE Fanuc IC697CGR935 单插槽控制器 用作控制器
