GE Fanuc IC697CBL700 电源延长电缆套件

【产品详情】

GE Fanuc IC697CBL700 电源延长电缆套件是一种预接线的高质量 3 英尺（1 米）电缆，适用于由于 I/O 使用时间延长而应将第二个 GE Fanuc 系列 90-70 PLC 机架添加到现有 PLC 中的应用。GE Fanuc IC697CBL700 电源延长电缆套件通过使用 9 针 D 型连接器为第二个 PLC 机架的运行提供所需的电力。用户应考虑的一个重要考虑因素是，将用于此应用的电源需要具有足够高的功率容量以满足两个 PLC 机架的要求，这意味着 PLC 机架的总负载应始终保持在电源容量范围内，以便应用程序可以成功部署。

GE Fanuc IC697CBL700 电源延长电缆套件设计用于在受到适当保护的工业外壳内运行，工作温度范围在 -25 至 +70 摄氏度（-13 至 158 华氏度）之间。GE Fanuc IC697CBL700 电源延长线套件也应存放在无湿度的地方，避免阳光直射，并且在准备安装之前不应将其从制造商提供的塑料袋和纸板箱中取出。延长电缆包括第二个 PLC 机架所需的 5 伏直流电源以及操作期间所需的附件 ACFAIL 和 SYSRESET 时序控制信号。机架间通信和总线接口模块单独出售，不是此电源扩展套件的标准设备。

90-70 系列IC697CBL700电缆是 GE Fanuc 制造的用于电源的延长电缆。IC697CBL700延长电缆的主要功能是在使用单个电源的同时操作 2 个不同的机架。第二个机架消耗的电流量比第一个机架小。IC697CBL700电缆可以直接插入背板安装的连接器。它适用于额定功率为 55 瓦和 100 瓦的 AC/DC 电源。IC697CBL700电缆可以一次将 5 伏的电源从电源断开器传输到第二个机架和控制信号。为了进行控制，电缆传输ACFAIL和SYSRESET信号。施加 5 V 总线电压后，ACFAIL 信号变为假。施加 200 伏电压后，SYSRESET 信号可在复位状态下保持长达 5 毫秒。

90-70 系列IC697CBL700延长电缆具有用于电缆连接的 9 针 D 型连接器。电缆的输入电压范围在 50 到 60 赫兹之间。延长电缆具有过压和过流保护功能。如果电源出现故障，保险丝会断开。延长电缆还配有盖板，以提供额外保护。可以使用 4 个 M2.5 螺钉进行安装。工作温度不应超过 50 摄氏度。对于高于 50 摄氏度的温度，应降低最大输出功率。IC697CBL700电缆可以在第二个机架插槽中容纳不同的 IC697 模块，这些模块可以在 12 伏电压下运行。在安装过程中，延长线不应弯曲过大，以免损坏。

GE Fanuc IC697CBL700 电源延长电缆套件

【英文介绍】

The GE Fanuc IC697CBL700 Power Extension Cable Kit is a pre-wired, high quality 3 ft (1 m) cable for applications where a second GE Fanuc series 90-70 PLC rack should be added to an existing PLC due to extended I/O usage time. The GE Fanuc IC697CBL700 Power Extension cable kit provides the power required for the operation of the second PLC rack by using 9-pin D-connectors. An important consideration that users should consider is that the power supply that will be used for this application needs to have a high enough power capacity to meet the requirements of two PLC racks, which means that the total load of the PLC rack should always be kept within the power supply capacity so that the application can be successfully deployed.

The GE Fanuc IC697CBL700 Power Extension Cable Kit is designed to operate in a properly protected industrial housing with an operating temperature range of -25 to +70 degrees Celsius (-13 to 158 degrees Fahrenheit). The GE Fanuc IC697CBL700 power extension cord kit should also be stored in a place free of humidity, out of direct sunlight, and should not be removed from the plastic bags and cardboard boxes provided by the manufacturer before it is ready for installation. The extension cable includes 5-volt DC power for the second PLC rack and accessory ACFAIL and SYSRESET timing control signals for the duration of operation. Interrack communication and bus interface modules are sold separately and are not standard equipment with this power expansion kit.

The 90-70 Series IC697CBL700 cable is an extension cable for power supplies manufactured by GE Fanuc. The main function of the IC697CBL700 extension cable is to operate 2 different racks while using a single power supply. The second rack consumes less current than the first rack. The IC697CBL700 cable can be plugged directly into the backplane mounted connector. It is suitable for AC/DC power supplies rated at 55 watts and 100 watts. The IC697CBL700 cable can transfer 5 volts of power at a time from the power breaker to the second rack and the control signal. For control, cables transmit ACFAIL and SYSRESET signals. After 5 V bus voltage is applied, the ACFAIL signal becomes false. After applying 200 volts, the SYSRESET signal can remain in the reset state for up to 5 milliseconds.

The 90-70 series IC697CBL700 extension cable has a 9-pin Type D connector for cable connections. The input voltage range of the cable is between 50 and 60 Hz. The extended cable provides protection against overvoltage and overcurrent. If the power supply fails, the fuse will disconnect. Extension cables are also fitted with cover plates for additional protection. It can be installed using four M2.5 screws. The operating temperature should not exceed 50 degrees Celsius. For temperatures above 50 degrees Celsius, the maximum output power should be reduced. The IC697CBL700 cable can accommodate different IC697 modules in the second rack slot, which can operate at 12 volts. During the installation process, the extension cable should not be bent too much to avoid damage.
