GE IC693CMM311 通信协处理器 配置系统

【产品详情】

概述

特征：

多才多艺

功能范围广

从简单的继电器更换为复杂的中档自动化

分立式和模拟量 I/O 模块

创新的架构和模块化设计

随着公司的发展扩展您的系统

凭借其模块化设计、100 多种不同的 I/O 模块和一系列 CPU 选项，90-30 系列为您提供了多功能性 根据您的特定性能需求配置系统。卓越的网络和通信功能使您能够通过一个非专有网络进行联网、传输数据、上传和下载程序以及执行诊断。集成到 90-30 系列中的运动控制有助于实现高性能的点对点应用，并支持各种电机类型和系统架构。

GE Fanuc IC693CMM311是一个通信协处理器模块。该组件为所有 90-30 系列模块化 CPU 提供高性能协处理器。它不能与嵌入式 CPU 一起使用。这涵盖了型号 311、313 或 323。该模块支持GE Fanuc CCM通信协议，SNP协议和RTU（Modbus）从属通信协议。可以使用配置软件配置模块。 或者，用户可以选择默认设置。它有两个串行端口。端口 1 支持 RS-232 应用，而端口 2 支持 RS-232 或 RS-485 应用。两个端口都连接到模块的单个连接器。因此，该模块配有星形电缆（IC693CBL305），以便将两个端口分开，使接线更容易。

在 CPU 为 4 或以上的系统中，最多可以使用 331 个通信协处理器模块。这只能通过 CPU 底板完成。在 4.0 之前的版本中，当两个端口都配置为 SNP 从设备时，此模块会出现特殊情况。在任一从设备收到的取消数据报请求中的 ID 值 –1 最终将取消同一 CMM 内两个从设备上所有已建立的数据报。这与CMM711模块不同，CMM4模块在串行端口上建立的数据报之间没有交互。0 年 693 月发布的 IC311CMM1996 <>.<> 版解决了这个问题。有此问题的旧版本模块请联系我们进行维修。

技术规格

模块类型： 通信协处理器

通信协议： GE Fanuc CCM， RTU （Modbus）， SNP

内部电源： 400 毫安 @ 5 伏直流

通信端口：

端口 1： 支持 RS-232

端口 2： 支持 RS-232 或 RS-485

GE Fanuc IC693CMM311通信协处理器模块用作扩展处理器，专门负责 90-30 系列模块化 CPU 的外部通信，特别是 311、313 或 323 型号。GE Fanuc IC693CMM311通信协处理器模块支持的一些通信协议是GE Fanuc CCM，SNP和RTU Modbus协议。串行端口 2 能够根据需要接收 RS-232 或 RS-485 通信。RS-693或RS-305协议的连接需要单独出售的星形电缆（部件号IC232CBL485），因为两种串行协议共享相同的连接端口。串行端口 1 专门用于 RS-232 应用。额定工作电压为 5 伏直流电，从 PLC 背板获取，额定电流为 400 毫安。

GE Fanuc IC693CMM311通信协处理器模块可通过使用专有手持配置工具或带有PCI卡的个人计算机上的专有软件进行简单配置。通信协处理器模块上唯一可见的指示灯 LED 是“模块正常”LED 和两个串行端口的状态 LED。如果模块未运行，GE Fanuc IC693CMM311通信协处理器模块的“模块OK”指示灯将熄灭，当模块正常工作时，该指示灯将亮起，并且在上电诊断期间将一直闪烁。控制最常见通信过程的所有必要信息都预加载到设备上，因此无需额外的自定义即可在解包后立即启动并运行模块。

GE IC693CMM311 通信协处理器 配置系统

【英文介绍】

summarize

Features:

versatile

Wide range of functions

Change from simple relays to complex mid-range automation

Discrete and analog I/O modules

Innovative architecture and modular design

Expand your system as your company grows

With its modular design, more than 100 different I/O modules and a range of CPU options, the 90-30 series gives you the versatility to configure your system according to your specific performance needs. Superior networking and communication capabilities enable you to network, transfer data, upload and download programs, and perform diagnostics over a non-proprietary network. Motion control integrated into the 90-30 series facilitates high-performance point-to-point applications and supports a wide range of motor types and system architectures.

GE Fanuc IC693CMM311 is a communication coprocessor module. This component provides high performance coprocessors for all 90-30 series modular cpus. It cannot be used with embedded cpus. This covers models 311, 313 or 323. The module supports GE Fanuc CCM communication protocol, SNP protocol and RTU (Modbus) slave communication protocol. Modules can be configured using configuration software. Alternatively, the user can select the default Settings. It has two serial ports. Port 1 supports RS-232 applications, while port 2 supports RS-232 or RS-485 applications. Both ports are connected to a single connector of the module. Therefore, the module is equipped with a star-shaped cable (IC693CBL305) in order to separate the two ports and make wiring easier.

In a system with a CPU of 4 or more, up to 331 communication coprocessor modules can be used. This can only be done through the CPU backboard. In versions prior to 4.0, this module presents a special case when both ports are configured as SNP slave devices. The ID value -1 in a cancellation datagram request received by either slave device will eventually cancel all established datagrams on both slave devices within the same CMM. Unlike the CMM711 module, the CMM4 module has no interaction between the datagrams established on the serial port. The IC311CMM1996 <>.<> version released in 1993 solved this problem. Older modules with this problem please contact us for repair.

Technical specification

Module type: communication coprocessor

Communication protocol: GE Fanuc CCM, RTU (Modbus), SNP

Internal power supply: 400 MA @ 5 V DC

Communication port:

Port 1: Supports RS-232

Port 2: Supports RS-232 or RS-485

The GE Fanuc IC693CMM311 communication coprocessor module is used as an extension processor and is specifically responsible for external communication of the 90-30 series modular cpus, especially the 311, 313 or 323 models. Some of the communication protocols supported by the GE Fanuc IC693CMM311 communication coprocessor module are the GE Fanuc CCM, SNP, and RTU Modbus protocols. Serial port 2 is capable of receiving RS-232 or RS-485 communications as needed. The connection of RS-693 or RS-305 protocols requires a star cable sold separately (part number IC232CBL485) because both serial protocols share the same connection port. Serial port 1 is designed for RS-232 applications. Rated operating voltage is 5 volts DC, obtained from the PLC backplane, rated current is 400 MA.

The GE Fanuc IC693CMM311 communication coprocessor module can be simply configured using proprietary handheld configuration tools or proprietary software on a personal computer with a PCI card. The only indicator leds visible on the communication coprocessor module are the "module normal" LED and the status leds for the two serial ports. If the module is not running, the "Module OK" indicator of the GE Fanuc IC693CMM311 communication coprocessor module will go off, will light up when the module is working normally, and will keep blinking during the power-on diagnosis. All the necessary information to control the most common communication processes is pre-loaded onto the device, so modules can be up and running immediately after unpacking without additional customization.

GE IC693CMM311 通信协处理器 配置系统
