GE IC693CBL324 伺服轴接线端子或辅助轴接线端子

【产品详情】

GE Fanuc IC693CBL324 终端板接口电缆是用于 90-30 系列 PLC 电缆系统的 I/O 接口电缆组件。此电缆将 DSM 模块连接到IC693ACC336辅助端子板和IC693ACC355轴端子板。IC693CBL324 端子板接口电缆提供长达 1 米（3.28 英尺）的电缆连接，可与 DSM 模块和轴接线端子或伺服轴接线端子连接。IC693ACC336辅助端子板有两个标有“DSM”和“SERVO”的 36 针连接器，用于连接 DSM 模块。DSM 模块还具有伺服轴连接器 A、B、C 和 D，用于数字和模拟伺服连接。IC693CBL324 端子板接口电缆在电缆的一端有一个 36 针连接器，用于连接到辅助端子板上的 36 针 DSM 端口，另一端的另一个 36 针连接器用于连接到 DSM 模块上的 PL2 连接器。

DSM 模块要求IC693ACC355轴端子板或辅助端子板通过IC693CBL325（3 米长）或IC693CBL324（1 米长）端子板接口电缆连接，以访问伺服轴 I/O 数据，例如过行程输入、原点开关输入或选通输入。安装时，如果应用需要使用 IC693ACC335 轴端子板访问 I/O 数据，例如超程或原位限制输入，则将 IC36CBL693 端子板接口电缆的 324 针连接器端连接到轴端子板上标有“DSM”的接线端子连接器，并将电缆的另一端连接到标有“A”的连接器，用于伺服轴 1， 或标记为“B”表示 DSM 模块上的伺服轴 2。

GE IC693CBL324 伺服轴接线端子或辅助轴接线端子

【英文介绍】

GE Fanuc IC693CBL324 Terminal board interface cable is an I/O interface cable assembly for the 90-30 series PLC cable system. This cable connects the DSM module to the IC693ACC336 auxiliary terminal board and the IC693ACC355 shaft terminal board. The IC693CBL324 Terminal board interface cable provides up to 1 meter (3.28 ft) cable connection to the DSM module and shaft terminal or servo shaft terminal. The IC693ACC336 auxiliary terminal board has two 36-pin connectors labeled "DSM" and "SERVO" for connecting DSM modules. The DSM module also features servo shaft connectors A, B, C and D for digital and analog servo connections. The IC693CBL324 Terminal board interface cable has a 36-pin connector on one end of the cable for connecting to the 36-pin DSM port on the auxiliary terminal board, and another 36-pin connector on the other end for connecting to the PL2 connector on the DSM module.

The DSM module requires the IC693ACC355 shaft terminal board or auxiliary terminal board to be connected via an IC693CBL325 (3 m long) or IC693CBL324 (1 m long) terminal board interface cable to access the servo shaft I/O data, such as over stroke input, origin switch input or strobe input. During installation, if the application requires access to I/O data using the IC693ACC335 shaft terminal board, such as over-the-range or in situ restricted inputs, connect the 324-pin connector end of the IC36CBL693 terminal board interface cable to the terminal connector labeled "DSM" on the shaft terminal board. And connect the other end of the cable to the connector labeled "A" for servo axis 1, or labeled "B" for servo axis 2 on the DSM module.

GE IC693CBL324 伺服轴接线端子或辅助轴接线端子
