GE IC693CBL300  I/O 总线扩展电缆

【产品详情】

IC693CBL300 是一种 I/O 总线扩展电缆，也称为“星形电缆”。它的一端有一个 25 针 D 公连接器，另一端有一个双头 25 针 D 连接器 - 一个公头，另一个母头。电缆尺寸为 3 英尺（1 米）。 这种预接线的 I/O 总线扩展电缆可用于连接扩展或远程底板。如果标准电缆的长度低于所需的电缆长度，则可以构建定制电缆。有两种类型的定制电缆：

点对点

怀

点对点电缆的一端有一个公连接器，另一端有一个母连接器。这种电缆更容易制作并节省时间。星形电缆的一端有一个公连接器，另一端有两个连接器（一个公头和另一个母头）。构建定制I / O总线扩展电缆所需的组件包括：

电缆本身 - 百通 8107。 它是一根双绞线 24 AWG （.22 mm2） 铜缆，额定电压为 30 V，可承受高达 80 度的电压。它的标称阻抗为 100 ̦，传播速度为 70%。

25 针插头

25 针母连接器

连接器外壳

IC693CBL300电缆是由GE Fanuc Automation设计和制造的总线扩展电缆，可与90-30系列高密度I / O模块一起使用。该电缆具有将模块与不同设备安全连接并在操作期间保持正确连接所需的所有规格。这种特殊的电缆长度为 1 米。当有超过 1 个机架时，此特定电缆可以以“菊花链”排列方式从一个机架连接到另一个机架。这是可能的，因为此GE Fanuc自动化电缆的一端带有双连接器。电缆的两端之一可以插入底板连接器，第二端可以提供用于连接下一根电缆的插座。该电缆旨在使用户能够构建自己的应用程序方案。

GE Fanuc Automation IC693CBL300总线扩展电缆可用作定制电缆和远程机架之间的星形适配器。该电缆的一端带有一个 25 针 D 公连接器，另一端带有支持“菊花链”连接的 2 头 25 针 D 连接器。此端有一个公连接器和一个母连接器。在使用“菊花链”电缆之前，该模块需要一根 1 米长的预接线电缆，以简化与此链条设置相关的定制电缆组件。GE Fanuc 自动化IC693CBL300总线扩展电缆能够互连底板扩展端口、CPU 和远程机架。它的制造旨在通过最小化整个系统的干扰水平来确保信号正确传输。该电缆是屏蔽的，可用于构建整个电缆和布线电路系统。

GE IC693CBL300  I/O 总线扩展电缆

【英文介绍】

The IC693CBL300 is an I/O bus expansion cable, also known as a "star cable". It has a 25-pin D male connector at one end and a double-ended 25-pin D connector at the other end - one male, the other female. Cable size is 3 feet (1 m). This pre-wired I/O bus expansion cable can be used to connect expansion or remote backboards. If the length of the standard cable is less than the required cable length, a custom cable can be built. There are two types of custom cables:

peer-to-peer

pregnant

A point-to-point cable has a male connector at one end and a female connector at the other end. This kind of cable is easier to make and saves time. The star cable has a male connector at one end and two connectors (one male and the other female) at the other end. The components needed to build a custom I/O bus expansion cable include:

The cable itself - Belton 8107. It is a twisted pair 24 AWG (.22 mm2) copper cable rated at 30 V and can withstand voltages up to 80 degrees. It has a nominal impedance of 100 ̦ and a propagation speed of 70%.

25-pin plug

25-pin female connector

Connector housing

The IC693CBL300 cable is a bus expansion cable designed and manufactured by GE Fanuc Automation that can be used with the 90-30 series high-density I/O modules. The cable has all the specifications needed to securely connect the module to different devices and maintain proper connections during operation. This special cable has a length of 1 meter. When there are more than 1 rack, this particular cable can be connected from one rack to another in a "Daisy chain" arrangement. This is possible because one end of this GE Fanuc automation cable has a double connector. One end of the cable can be plugged into a baseboard connector, and the second end can provide a socket for connecting the next cable. The cable is designed to enable users to build their own application scenarios.

The GE Fanuc Automation IC693CBL300 bus expansion cable can be used as a star adapter between custom cables and remote racks. The cable has a 25-pin D male connector on one end and a 2-head 25-pin D connector that supports a "Daisy chain" connection on the other end. This end has a male connector and a female connector. Prior to the use of the "Daisy chain" cable, the module required a 1 meter long pre-wired cable to simplify the custom cable assembly associated with this chain setup. GE Fanuc Automation IC693CBL300 bus expansion cable interconnects baseboard expansion ports, cpus, and remote racks. It is manufactured to ensure that signals are transmitted correctly by minimizing the level of interference throughout the system. The cable is shielded and can be used to build entire cable and wiring circuit systems.

GE IC693CBL300  I/O 总线扩展电缆
