531X305NTBANG1  NTB/3TB 终端板 电源和编码器

【产品详情】

通用电气制造了531X305NTBANG1卡，用作NTB / 3TB终端板。该端子板是作为 531X 系列替换驱动和励磁器板的成员开发的。 该板提供了许多接口系统功能。 该卡的功能包括继电器和串行输出、模拟量 I/O、电源和编码器。

安装此NTB/3TB终端板时，它为驱动器提供了一系列功能。安装时，531X305NTBANG1能够产生稳压和非稳压电源。稳压电源速率为 5 VDC 和 15 VDC，而非稳压电源的额定电压为 24 VDC 或 125 VAC。额定电压为 5 V 和 15 V 的编码器可以使用板载跳线进行配置。该板还包括七个继电器输出，由 A 型或 C 型输出组成。每个继电器内的触点的额定值为 120 VAC。低电平模拟I/O也可以使用板上的四个电位计进行缩放。

531X305NTBANG1 NTB/3TB 终端板包含许多安装参数。在开始设备安装之前查看这些指南将有助于降低电路板损坏的风险。

531X305NTBANG1  NTB/3TB 终端板 电源和编码器

【英文介绍】

Ge manufactured 531X305NTBANG1 cards for use as NTB / 3TB terminal boards. The terminal board was developed as a member of the 531X series replacement driver and exciter board. The board provides many interface system functions. The card features include relays and serial outputs, analog I/O, power supply, and encoder.

When this NTB/3TB terminal board is installed, it provides a range of functions for the drive. When installed, the 531X305NTBANG1 is capable of generating both regulated and unregulated power supplies. Regulated power supply rates are 5 VDC and 15 VDC, while non-regulated power supplies are rated at 24 VDC or 125 VAC. Encoders rated at 5 V and 15 V can be configured using onboard jumpers. The board also includes seven relay outputs, consisting of type A or Type C outputs. The contacts within each relay are rated 120 VAC. Low-level analog I/O can also be scaled using the four potentiometers on the board.

The 531X305NTBANG1 NTB/3TB terminal board contains many installation parameters. Reviewing these guidelines before starting a device installation will help reduce the risk of board damage.
