IC670MDD441 混合 I/O 模块   直流模块

【产品详情】

GE Fanuc IC670MDD441 I/O 模块是 GE 现场控制系列的混合 I/O 模块，具有 6 个输出和 10 个输入，总共 16 个 I/O。IC670MDD441 I/O 模块是在 24 伏直流电下运行的直流模块。输入和输出电路都是分立的I/O，它们共用一条线路。所有6个输出均具有短路保护和电子过流保护，如果发生短路或电子过流情况，它们可以发出警报。发生故障时，遇到故障的输出将关闭，故障将报告给系统的BIU或总线接口单元。

该系统的BIU还为GE现场控制IC670MDD441 I / O模块提供电源。但是，为该系统中的负载供电的开关需要外部直流电源。IC670MDD441 I/O 模块侧面的绿色 LED 在其相应的输入通电时亮起。模块侧面的双色 LED 在其相应的输出通电时呈绿色亮起，当相应的输出出现故障时，它们会发出橙色光。当IC670MDD441 I/O 模块具有逻辑和用户电源且模块关闭且未通电时，“PWR”LED 呈绿色亮起。该模块的导通电压范围为 15 至 30 伏直流电，其关断电压范围为 0 至 5 伏直流电。

IC670MDD441 混合 I/O 模块   直流模块

【英文介绍】

The GE Fanuc IC670MDD441 I/O module is a hybrid I/O module in the GE Field Control family, with 6 outputs and 10 inputs for a total of 16 I/ OS. The IC670MDD441 I/O module is a DC module operating at 24 volts DC. Both the input and output circuits are discrete I/ OS, and they share a single line. All six outputs have short circuit protection and electronic overcurrent protection, which can sound an alarm if a short circuit or electronic overcurrent situation occurs. In the event of a failure, the output experiencing a failure is shut down and the fault is reported to the system's BIU or bus interface unit.

The system's BIU also provides power for the GE field control IC670MDD441 I/O module. However, the switches that power the loads in this system require an external DC power supply. The green LED on the side of the IC670MDD441 I/O module lights up when its corresponding input is powered on. The two-color leds on the side of the module light up green when their corresponding outputs are powered on, and they glow orange when the corresponding outputs fail. When the IC670MDD441 I/O module has logical and user power and the module is off and not powered on, the "PWR" LED lights up green. The module has an on-voltage range of 15 to 30 volts DC and a turn-off voltage range of 0 to 5 volts DC.

IC670MDD441 混合 I/O 模块   直流模块

【其他型号推荐】

The GE Fanuc IC670MDD441 I/O module is a hybrid I/O module in the GE Field Control family, with 6 outputs and 10 inputs for a total of 16 I/ OS. The IC670MDD441 I/O module is a DC module operating at 24 volts DC. Both the input and output circuits are discrete I/ OS, and they share a single line. All six outputs have short circuit protection and electronic overcurrent protection, which can sound an alarm if a short circuit or electronic overcurrent situation occurs. In the event of a failure, the output experiencing a failure is shut down and the fault is reported to the system's BIU or bus interface unit.

The system's BIU also provides power for the GE field control IC670MDD441 I/O module. However, the switches that power the loads in this system require an external DC power supply. The green LED on the side of the IC670MDD441 I/O module lights up when its corresponding input is powered on. The two-color leds on the side of the module light up green when their corresponding outputs are powered on, and they glow orange when the corresponding outputs fail. When the IC670MDD441 I/O module has logical and user power and the module is off and not powered on, the "PWR" LED lights up green. The module has an on-voltage range of 15 to 30 volts DC and a turn-off voltage range of 0 to 5 volts DC.
