GE IC695PBS301 从站模块 提供从属通信

【产品详情】

技术规格

模块类型： Profibus从站模块

指示灯： PROFIBUS 正常、网络、模组状态

背板支持： 普遍

# 插槽数： 1（单插槽）

港口： 9 针连接器

功耗： 440 毫安 @ 3.3 伏直流

IC695PBS301模块是GE Fanuc在RX3i PacSystems产品线中制造的PROFIBUS从站模块。它旨在通过 PROFIBUS DP 网络提供从属通信，并具有 LED 指示灯，包括“MOD 状态”、“网络”和“PROFIBUS OK”指示灯以及对通用背板的支持。GE Fanuc IC695PBS301模块具有一个 9 针连接器、一个单插槽，额定电压为 440.3 伏直流电时额定功耗为 3 毫安。该 PROFIBUS 从模块支持所有标准数据速率，可在 0 至 60 摄氏度的温度范围内工作，并且可以在 -40 至 85 摄氏度的温度范围内存储。从模块自动与主设备交换数据。它无权访问总线，但它可以确认收到的消息或在请求时将它们传输到主设备。

IC695PBS301 PROFIBUS 从模块支持广泛的 PROFIBUS 通信功能，包括从网络读取高达 244 字节的输入数据负载和传输高达 244 字节的输出数据负载的能力。它还支持所有标准 PROFIBUS 数据速率以及 DP-V1 读写和报警消息。IC695PBS301模块通过使用WinLoader软件实用程序通过主机控制器CPU间接接收固件升级。此WinLoader软件附带了PROFIBUS模块软件的更新。绿色的“PROFIBUS OK”指示灯显示电源和完全底板复位。黄色双色“网络”LED 显示模块可以传输 PROFIBUS 报文，如果存在严重的通信问题，它将变为红色。双色“MOD 状态”LED 显示模块的运行状态。

GE IC695PBS301 从站模块 提供从属通信

【英文介绍】

Technical specification

Module type: Profibus Slave module

Indicator: PROFIBUS normal, network, and module status

Backplane support: Universal

# Number of slots: 1 (single slot)

Port: 9 pin connector

Power consumption: 440 MA @ 3.3 V DC

The IC695PBS301 module is a PROFIBUS slave module manufactured by GE Fanuc in the RX3i PacSystems product line. It is designed to provide slave communication over the PROFIBUS DP network and features LED indicators including "MOD Status", "Network" and "PROFIBUS OK" indicators as well as support for a universal backplane. The GE Fanuc IC695PBS301 module features a 9-pin connector, a single slot, and a power rating of 3 mA at 440.3 VDC. The PROFIBUS slave module supports all standard data rates, operates in a temperature range of 0 to 60 degrees Celsius, and can be stored in a temperature range of -40 to 85 degrees Celsius. The slave module automatically exchanges data with the master device. It does not have access to the bus, but it can acknowledge the messages it receives or transmit them to the master device when requested.

The IC695PBS301 PROFIBUS slave module supports a wide range of PROFIBUS communication capabilities, including the ability to read input data loads of up to 244 bytes from the network and transmit output data loads of up to 244 bytes. It also supports all standard PROFIBUS data rates as well as DP-V1 read/write and alarm messages. The IC695PBS301 module receives firmware upgrades indirectly through the host controller CPU by using the WinLoader software utility. This WinLoader software comes with an update to the PROFIBUS module software. The green "PROFIBUS OK" indicator indicates power and complete backboard reset. The yellow two-color "network" LED display module can transmit PROFIBUS messages, and it will turn red if there is a serious communication problem. The two-color "MOD Status" LED displays the operating status of the module.
