GE IC695PBM300 支持所有标准数据速率 可编程自动化控制器

【产品详情】

该IC695BPM300是一个Profibus Master模块，以前由GE智能平台（GE IP）制造，现在属于艾默生自动化的PACSystems RX3i可编程自动化控制器（PAC）系列。该模块用于通过Profibus网络实现数据交换，最大输入数据为3,584字节，输出数据为3,584字节。该Profibus主模块支持多达125个DP从机的通信，每个DP从站可以发送244字节的输入数据并接收244字节的输出数据。

IC695BPM300支持所有标准数据速率，特别是9.6 kBit/s，19.2 kBit/s，93.75 kBit/s，187.5 kBit/s，500 kBit/s，1.5 MBit/s，3 MBit/s，6 MBit/s和12 MBit/s。它可以提供状态信息，如从状态位阵列表、网络诊断计数器、DP主诊断计数器、固件模块修订和从诊断地址。它安装在 RX3i 背板上，支持 PCI 连接。具体来说，它必须安装在带有运行固件版本 3.2 或更高版本的主机 PACSystem RX9i 控制器的通用背板上。它吸收的背板电流为 440 mA @ 3.3 VDC。

该模块配有一个Profibus OK ED指示器;网络指示器;和 MOD 状态指示器。该模块支持同步和冻结模式以及 Profibus DP-V1 读、写和报警消息。IC695BPM300带有可升级的固件，该固件通过主机控制器通过WinLoader软件实用程序间接接收。

该模块必须在 0 至 60 摄氏度的温度范围内运行，而模块的存储温度为 -40 至 85 摄氏度。

IC695PBM300 PROFIBUS主模块由GE智能平台/GE Fanuc在RX3i PacSystems系列中制造。该模块旨在使 RX3i CPU 能够通过 PROFIBUS-DP 网络发送或接收数据。它具有单个插槽，支持通用背板和RS-232通信端口。IC695PBM300 PROFIBUS 模块在 440.3 伏直流额定电压下具有 3 毫安的内部额定电流，并支持多达 125 个 PROFIBUS-DP 从站单元的协议。该模块的其他显著特性包括支持高达 244 字节速率的输入数据和每个从站单元高达 244 字节的输出数据、支持所有标准数据速率以及同步和冻结模式。该模块还支持 DP-V1 读写功能和报警消息以及网络状态 LED 指示灯和符合 PROFIBUS 标准的模块。它支持高达 3584 字节的输入数据和 3584 字节的总输出数据速率。

GE IC695PBM300 支持所有标准数据速率 可编程自动化控制器

【英文介绍】

The IC695BPM300 is a Profibus Master module formerly manufactured by GE Intelligent Platform (GE IP) and now belongs to Emerson Automation's PACSystems RX3i Programmable Automation Controller (PAC) family. The module is used for data exchange over the Profibus network with a maximum input data of 3,584 bytes and output data of 3,584 bytes. The Profibus master module supports the communication of up to 125 DP slaves, each of which can send 244 bytes of input data and receive 244 bytes of output data.

The IC695BPM300 supports all standard data rates, in particular 9.6 kBit/s, 19.2 kBit/s, 93.75 kBit/s, 187.5 kBit/s, 500 kBit/s, 1.5 MBit/s, 3 MBit/s, and more. 6 MBit/s and 12 MBit/s. It can provide state information such as slave state bit array table, network diagnostic counter, DP master diagnostic counter, firmware module revision, and slave diagnostic address. It is installed on the RX3i backplane and supports PCI connectivity. Specifically, it must be installed on a universal backplane with a host PACSystem RX9i controller running firmware version 3.2 or higher. The backplane current it absorbs is 440 mA @ 3.3 VDC.

The module is equipped with a Profibus OK ED indicator; Network indicator; And MOD status indicator. The module supports sync and freeze modes as well as Profibus DP-V1 read, write, and alarm messages. The IC695BPM300 comes with upgradable firmware, which is received indirectly by the host controller via the WinLoader software utility.

The module must operate in a temperature range of 0 to 60 degrees Celsius, while the storage temperature of the module is -40 to 85 degrees Celsius.

The IC695PBM300 PROFIBUS main module is manufactured by GE Intelligent Platform /GE Fanuc in the RX3i PacSystems family. The module is designed to enable the RX3i CPU to send or receive data over the PROFIBUS-DP network. It has a single slot, supports a universal backplane and an RS-232 communication port. The IC695PBM300 PROFIBUS module has an internal current rating of 3 mA at a 440.3 VDC rating and supports protocols for up to 125 PROFIBUS-DP slave station units. Other notable features of the module include support for up to 244 bytes of input data and up to 244 bytes of output data per slave unit, support for all standard data rates, and sync and freeze modes. The module also supports DP-V1 read/write functions and alarm messages as well as network status leds and PROFIBUS compliant modules. It supports up to 3584 bytes of input data and a total output data rate of 3584 bytes.
