GE lC695MDL765 数字输入模块 外部供电电压

【产品详情】

该IC694MDL645是艾默生自动化（前身为GE智能平台（GE IP））的PACsystem RX3i系列的数字输入模块。该输入模块设计有十六 （16） 个输入通道，兼容正或负逻辑接线。该模块具有一组输入和一个公共终端。每个输入通道设计为接收 0-30 VDC 输入范围的输入电压范围和 24 VDC 的额定电压。

每个输入通道的导通状态电压为 11.5 - 30 VDC，关断状态电压为 0-5VDC，最小输入电流为 3.2 mA，最大输入电流为 1.1 mA。该模块的典型响应时间为每通道 7 ms，功耗为 80 mA @ 5VDC 和 125 mA @ 24VDC 背板总线或外部供电电压。该模块还具有 250 VAC 和 1500 VAC 的连续隔离额定值，持续 1 分钟。这种隔离是从Field到背板，也称为光隔离和帧到地隔离。

该IC694MDL645可以作为RX3i系统的本地输出模块组件以及同一系统的分布式I/O组件安装。此外，它还支持 RX7i 系统，仅用作分布式 I/O。该模块还提供十六 （16） 个输出 LED，代表每个输入通道。有源输入通道将使其相应的 LED 通电，否则，LED 保持断电状态。该模块特别兼容开/关设备，如开关、按钮设备、接近传感器和辅助触点。

RX694i PacSystem 系列的 GE Fanuc IC645MDL3 输入模块的额定电压为 24 伏直流电（具有正逻辑或负逻辑）、7 毫安输入电流、0 至 30 伏直流电的输入电压范围、80 伏总线源的额定功耗为 5 毫安和 125 伏电源的 24 毫安额定功率。它有 16 个输入点，所有输入点都排列在一个组中，并带有一个共享电源输入端子。它连接为负逻辑或正逻辑。GE Fanuc IC694MDL645输入模块具有各种输入特性，例如 11.5 至 30 伏直流电的导通电压、0 至 5 伏直流电的关断电压、最小 3.2 毫安的导通电流、最大 1.1 毫安的关断电流、平均 7 毫秒的导通响应时间和平均 7 毫秒的关断响应时间。

GE lC695MDL765 数字输入模块 外部供电电压

【英文介绍】

The IC694MDL645 is a digital input module for Emerson Automation's PACsystem RX3i family, formerly GE Intelligence Platform (GE IP). The input module is designed with sixteen (16) input channels compatible with positive or negative logic wiring. The module has a set of inputs and a common terminal. Each input channel is designed to receive an input voltage range of 0-30 VDC input range and a rated voltage of 24 VDC.

The on-state voltage of each input channel is 11.5-30 VDC, the off state voltage is 0-5VDC, and the minimum input current is 3.2 mA and the maximum input current is 1.1 mA. The module has a typical response time of 7 ms per channel and power consumption of 80 mA@5VDC and 125 mA@24VDC for the backplane bus or external supply voltage. The module also has a continuous isolation rating of 250 VAC and 1500 VAC for 1 minute. This isolation is from Field to backplane, also known as optical isolation and frame-to-ground isolation.

The IC694MDL645 can be installed as a local output module component of an RX3i system as well as a distributed I/O component of the same system. In addition, it supports RX7i systems for distributed I/O use only. The module also provides sixteen (16) output leds, representing each input channel. The active input channel energizes its corresponding LED, otherwise, the LED remains powered off. The module is particularly compatible with on/off devices such as switches, push button devices, proximity sensors and auxiliary contacts.

The GE Fanuc IC645MDL3 input module of the RX694i PacSystem family is rated for 24 VDC (with positive or negative logic), 7 MA input current, 0 to 30 VDC input voltage range, and 5 MA power consumption for 80 volt bus sources 24 mah rating for 125 volt supply. It has 16 input points, all arranged in a group, with a shared power input terminal. It is connected as negative logic or positive logic. GE Fanuc IC694MDL645 Input modules with various input characteristics, For example, a turn-on voltage of 11.5 to 30 volts DC, a turn-off voltage of 0 to 5 volts DC, a minimum turn-on current of 3.2 MA, a maximum turn-off current of 1.1 MA, an average turn-on response time of 7 ms, and an average turn-off response time of 7 ms.
