GE lC695HSC308 高速计数器模块 适用于工业控制应用

【产品详情】

产品描述

IC695HSC308是GE Fanuc RX3i系列的高速计数器模块。该模块可直接处理高达 1.5 MHz 的快速脉冲信号，适用于工业控制应用。请在IC695HSC308的网站页面上查看本机的规格。

技术规格

处理速度： 1.5兆赫

输入电压范围： 5 V 直流或 12 至 24V 直流

输出电压范围： 4.7 至 40V 直流

模块类型： 高速计数器

输入/输出类型： 正逻辑

功耗： 457mA @ 3.3V， 64 mA @ 5V

其他信息

IC695HSC308高速计数器模块

IC695HSC308是GE Fanuc RX3i系列的高速计数器模块。

GE PLC授权经销商IC695HSC308系列RX3i并不是GE PLC的唯一来源。许多GE PLC产品已经停产，因此不再从GE自动化的GE授权供应商处获得。PDF 供应有所有新的和过时的GE系列RX3i PLC零件库存。

产品代码IC695HSC308是由GE Fanuc设计和制造的高速计数器模块的产品代码，它是RX3i PACSystems系列的一部分。该模块提供端子块插入、使用闪存进行升级、可配置的 I/O 中断以及热插入和拔出等功能。IC695HSC308模块的参数可以轻松更改，无需再次配置。该模块安装在 RX3i 通用背板上，用于速度测量、仪表检定、涡轮流量计、运动控制和过程控制应用等应用。

IC695HSC308模块符合 CE、UL/cUL 508、1604 和 ATEX 标准等标准的要求。该模块具有 8 个计数器通道，用于 16 个输入和 14 个输出。此外，此高速计数器可以配置为用户定义的计数器类型，也可以配置为 A、B、C、D、E 或 Z 型。该装置配有用于显示模块状态、现场状态和接线端子状态的 LED 指示灯。IC695HSC308模块的隔离电压为 250 伏交流连续和 2500 伏交流电，持续 1 分钟。隔离电压是指场对背板（光学）电压和场对帧接地电压。该装置的最大导通状态压降/输出为 0.35 伏（1.5 安培），最小负载电流为 0 毫安。IC695HSC308模块的输出电流额定值高达每通道 1.5 安培，每个模块最大 10.5 安培。该模块的标称输入电压为 5 伏直流或 12 至 24 伏直流。峰值输入电压为 35 伏直流电。

GE lC695HSC308 高速计数器模块 适用于工业控制应用

【英文介绍】

Product description

The IC695HSC308 is a high speed counter module in the GE Fanuc RX3i series. The module can directly process fast pulse signals up to 1.5 MHz and is suitable for industrial control applications. Please check the specifications of the unit on the IC695HSC308 website page.

Technical specification

Processing speed: 1.5 MHZ

Input voltage range: 5 V DC or 12 to 24V DC

Output voltage range: 4.7 to 40V DC

Module type: High speed counter

Input/Output type: positive logic

Power consumption: 457mA@3.3V, 64 mA@5V

Other information

IC695HSC308 High speed counter module

The IC695HSC308 is a high speed counter module in the GE Fanuc RX3i series.

Authorized distributor

GE PLC authorized distributor IC695HSC308 series RX3i is not the only source of GE PLC. Many GE PLC products have been discontinued and are therefore no longer available from GE Automation's GE authorized suppliers. PDF supply has an inventory of all new and obsolete GE series RX3i PLC parts.

Product code IC695HSC308 is the product code for a high speed counter module designed and manufactured by GE Fanuc as part of the RX3i PACSystems family. The module provides terminal block insertion, upgrades using flash memory, configurable I/O interrupts, and hot insert and unplug. The parameters of the IC695HSC308 module can be easily changed without reconfiguration. The module is mounted on the RX3i universal backplane and is used for applications such as speed measurement, instrument verification, turbine flowmeters, motion control and process control applications.

The IC695HSC308 module complies with standards such as CE, UL/cUL 508, 1604 and ATEX standards. The module has 8 counter channels for 16 inputs and 14 outputs. In addition, this high-speed counter can be configured as A user-defined counter type or as type A, B, C, D, E, or Z. The unit is equipped with LED indicators for displaying module status, field status and terminal status. The isolation voltage of the IC695HSC308 module is 250 V AC continuous and 2500 V AC for 1 minute. Isolation voltage refers to the field-to-backplane (optical) voltage and field-to-frame grounding voltage. The device has a maximum on-state voltage drop/output of 0.35 volts (1.5 amps) and a minimum load current of 0 mA. The IC695HSC308 module has an output current rating of up to 1.5 amps per channel and a maximum of 10.5 amps per module. The module has a nominal input voltage of 5 volts DC or 12 to 24 volts DC. The peak input voltage is 35 volts DC.

GE lC695HSC308 高速计数器模块 适用于工业控制应用
