IC695CBLO03 GE Fanuc系列90-30 PLC的HHP和转换器电缆

【产品详情】

IC693CBL303是GE Fanuc系列90-30 PLC的HHP和转换器电缆。它长 6 英尺，将手持式编程器与可编程逻辑控制器连接起来。它的每一端都有一个 15 针公头 D 超小型和佳能 DA15 型连接器。电缆类型为百通 8508，配有连接器外壳、公制螺钉和螺钉夹。要使用 IC693CBL303 HHP 和转换器电缆，请将 15 针 D 连接器连接到 PLC 的串行端口。另一端连接到 HPP 底部的配接连接器。连接 HPP 时，电缆将提供电源并向 PLC 发送信号。

除了GE Fanuc IC693CBL303 HHP和90-30系列转换器电缆之外，还可以创建定制电缆。 如果是这种情况，它可以长达 300 英尺，并且需要单独的电源。定制电缆所需的电缆类型是百通9309型电缆，并且需要+5 VDC的外部电源。9 针连接器的针脚 10 和 15 必须跳线。PLC电源的+5V和SG连接必须与电源线接地连接分离。电缆连接器的+5V引脚不得连接到PLC。GE Fanuc C693CBL303 HHP 和转换器电缆的另一个用途是将 PLC 连接到 RS-232 转换器。PLC可以通过RS-422串行端口或PC兼容计算机连接到编程器。

IC695CBLO03 GE Fanuc系列90-30 PLC的HHP和转换器电缆

【英文介绍】

The IC693CBL303 is an HHP and converter cable for GE Fanuc series 90-30 PLCS. It is 6 feet long and connects a handheld programmer to a programmable logic controller. It has a 15-pin male D subminiature and Canon DA15 type connector at each end. Cable type is Belton 8508 with connector housing, metric screws and screw clamps. To use the IC693CBL303 HHP and converter cable, connect the 15-pin D connector to the PLC's serial port. The other end is connected to the mating connector at the bottom of the HPP. When the HPP is connected, the cable will provide power and send a signal to the PLC.

In addition to the GE Fanuc IC693CBL303 HHP and 90-30 series converter cables, custom cables can also be created. If this is the case, it can be up to 300 feet long and requires a separate power source. The cable type required for the custom cable is the Belton 9309 cable and requires an external power supply of +5 VDC. Pins 10 and 15 of the 9-pin connector must be jumped. The +5V and SG connections of the PLC power supply must be separated from the power cable ground connection. The +5V pin of the cable connector must not be connected to the PLC. Another use of the GE Fanuc C693CBL303 HHP and converter cable is to connect the PLC to the RS-232 converter. The PLC can be connected to the programmer via the RS-422 serial port or a PC-compatible computer.
