IC695ACC651 GE  I / O适配器

【产品详情】

IC695ACC651适配器是由GE Fanuc设计和制造的RX3i PacSystems系列I / O适配器。它有助于将 90-70 系列模块现场接线与 RX3i 模块连接。它与分立式 I/O 模块和其他模拟模块兼容。适配器支持 240 伏的额定电压，额定电流为 8 安培。周围环境的空气温度不应超过60摄氏度。IC695ACC651 I/O 适配器已通过 UL 1 类 2 分区标准认证。适配器的正面有 LED 指示灯。适配器的背面有一个接线端子，用于与 RX3i 模块连接。模块中的每个单独点都单独融合。

IC695ACC651 I/O 适配器具有模制闩锁，可帮助其连接到转换机架的上下导轨。要将适配器固定到位，请使用 M 2.5 套环螺钉。它的扭矩为 1.1 N-m。卸下适配器卡时，应完全断开电源。该模块以 47 至 63 赫兹范围内的正弦频率工作。IC695ACC651 I/O 适配器具有 1500 V 的隔离额定值，适用于适配器背板的任何输出。单周期的浪涌电流为 20 安培。该模块采用开放式架构设计，应安装在没有空气污染物的环境中。IC695ACC651 I/O 适配器可与编程端子或计算机连接以进行配置。Proficy软件可用于配置和编程模块。

IC695ACC651 GE  I / O适配器

【英文介绍】

The IC695ACC651 adapter is an RX3i PacSystems series I/O adapter designed and manufactured by GE Fanuc. It helps connect the 90-70 series module field wiring to the RX3i module. It is compatible with discrete I/O modules and other analog modules. The adapter supports 240 volts of rated voltage and 8 amps of rated current. The ambient air temperature should not exceed 60 degrees Celsius. The IC695ACC651 I/O adapter is certified to UL Class 1 2 Partition standard. There are LED indicators on the front of the adapter. The back of the adapter has a terminal for connecting to the RX3i module. Each individual point in the module is fused separately.

The IC695ACC651 I/O adapter has a molded latch that helps it connect to the upper and lower rails of the conversion rack. To hold the adapter in place, use M 2.5 collar screws. It has a torque of 1.1 N-m. Disconnect the power completely when removing the adapter card. The module operates at sinusoidal frequencies in the 47 to 63 Hz range. The IC695ACC651 I/O adapter has an isolation rating of 1500 V and is suitable for any output on the adapter backplane. The single period surge current is 20 amps. The module has an open architecture design and should be installed in an environment free of air pollutants. The IC695ACC651 I/O adapter can be connected to a programming terminal or computer for configuration. Proficy software is available for configuration and programming modules.

IC695ACC651 GE  I / O适配器
