GE IC694PWR330 大容量串行扩展电源模块

【产品详情】

技术规格

标称额定电压： 120/240 伏交流电或 125 伏直流

输入电压范围： 85 至 264 VAC 或 100 至 300 VDC

输入功率： 100 VA 带交流电或 50 瓦（带伏直流电）

负载能力： 30 瓦

模块类型： 扩展电源

背板支持： 仅限远程基地

IC694PWR330大容量串行扩展电源模块由GE Fanuc制造，用作GE RX3i PacSystems可编程逻辑控制器或PLC的扩展电源。IC694PWR330电源模块可与 RX3i 产品系列中的任何 CPU 配合使用，可为 PLC 提供高达 30 瓦的额外功率。当此模块安装在PLC中时，由于它是串行扩展设备，因此应安装在PLC串行扩展背板中。切勿在接通电源时尝试从串行扩展底板上安装或卸下此模块，否则可能会发生用户伤害或组件损坏。其额定电流为 2 安培，并使用 GE 44A724627-109 保险丝进行保护。

GE Fanuc RX3i IC694PWR330大容量串行扩展电源模块只有在正确设置背板的机架号选择DIP开关后才能安装在串行扩展背板上。此电源模块的标称输入电压额定值为 120/240 伏交流电和 125 伏直流电。IC694PWR330电源模块不支持负载共享冗余，但它可以支持 30 伏直流电压下的 5 瓦负载、20 伏直流隔离电压下的 24 瓦负载和 15 伏直流继电器电压下的 24 瓦负载。它可以在一英寸或 12.1 N-m 上处理 3 磅的扭矩水平。IC694PWR330电源模块的输入电压额定值为 85 至 264 伏交流电和 100 至 300 伏直流电。

GE IC694PWR330 大容量串行扩展电源模块

【英文介绍】

Technical specification

Nominal voltage: 120/240 volts AC or 125 volts DC

Input voltage range: 85 to 264 VAC or 100 to 300 VDC

Input power: 100 VA with AC or 50 watts (with VDC)

Load capacity: 30 watts

Module type: Expansion power supply

Backplane support: Remote base only

The IC694PWR330 High capacity Serial expansion power module is manufactured by GE Fanuc and is used as an expansion power supply for GE RX3i PacSystems programmable logic controllers or PLCS. The IC694PWR330 power module can be used with any CPU in the RX3i product family to provide up to 30 watts of additional power to the PLC. When this module is installed in a PLC, since it is a serial expansion device, it should be installed in the PLC serial expansion backplane. Do not attempt to install or remove this module from the serial expansion baseplate while powering on, as user injury or component damage may occur. It is rated at 2 amps and is protected with a GE 44A724627-109 fuse.

GE Fanuc RX3i IC694PWR330 Large capacity Serial expansion power module can only be installed on the serial expansion backplane after the rack number of the backplane is correctly set and the DIP switch is selected. The nominal input voltage ratings for this power supply module are 120/240 volts AC and 125 volts DC. The IC694PWR330 power module does not support load sharing redundancy, but it can support 5 watts of load at 30 volts DC, 24 watts of load at 20 volts DC isolation voltage and 24 watts of load at 15 volts DC relay voltage. It can handle a torque level of 3 pounds on an inch or 12.1 N-m. The input voltage ratings of the IC694PWR330 power module are 85 to 264 volts AC and 100 to 300 volts DC.

GE IC694PWR330 大容量串行扩展电源模块
