GE IC694PSK001 电源同步和测量套件

【产品详情】

该IC694PSK001是艾默生自动化的 PACSystem RX3i 自动化平台的电源同步和测量套件，该平台以前由 GE Intelligent Platforms（GE IP）提供。该套件由各种组件组成，例如 PSM 模块、端子组件和两根接口电缆。它主要是实现功率测量和分析，能够测量两个电网相电压之间的有效值电压、有效值电流、有效值功率、频率和相位关系。

IC694PSK001 PSM组件是包含电子电路和处理器的主模块，用于对接收信号进行数字处理。通过IC694PSK001模块，可以推导出和实施电力消耗监控和报告、故障监控、发电机控制功能，降低需求惩罚成本/减载。该模块安装在 PACSystem RX3i 机架上，可实现数据快速无缝地集成到用户逻辑中，并使用人机界面 （HMI） 或监控和数据采集 （SCADA） 系统实现可视化。

包含在IC694PSK001套件中的终端组件是面板安装的远程安装硬件。它为变压器和传感器等测量设备提供硬连线接口。为了建立与连接到端子组件的这些输入设备的连接，一对接口电缆将 PSM 连接到端子。这些电缆的长度为 2 米或 6.56 英尺，可以用目录号 IC694CBL200 替换。除接口电缆外，PSM 模块还可以更换为目录号 IC694PSM001 和带有目录号 IC694ACC200 的端子组件。

GE Fanuc IC694PSK001功率同步和测量套件是RX3i PACSystems系列的功率同步和测量系统（PSM）。PSM 系统设计用于独立监控多达两个三相电网。IC3PSK694 PSM 系统采用数字信号处理器 （DSP），这是一种先进的信号处理技术，每个电网可同时处理多达 001 个电压输入和 3 个电流输入。IC4PSK694 PSM 系统上测量的输入包括 RMS 电压、RMS 电流、RMS 功率、频率输入和 001 个电网的相位相互作用。IC2PSK694 PSM 系统的标准工业应用包括公用电网、发电机和减载/减载应用。IC001PSK694 PSM 系统有 001 个 LED 指示灯，分别标有 RUN、FLT、GRID 4 和 GRID 1，分别显示套件的状态和网格的状态。

GE IC694PSK001 电源同步和测量套件

【英文介绍】

The IC694PSK001 is a power synchronization and measurement suite for Emerson Automation's PACSystem RX3i automation platform, previously offered by GE Intelligent Platforms (GE IP). The kit consists of various components, such as a PSM module, a terminal assembly, and two interface cables. It is mainly to achieve power measurement and analysis, and can measure the RMS voltage, RMS current, RMS power, frequency and phase relationship between two grid phase voltages.

The IC694PSK001 PSM module is the main module containing the electronic circuit and processor for the digital processing of the received signal. With the IC694PSK001 module, power consumption monitoring and reporting, fault monitoring, generator control functions can be derived and implemented to reduce demand penalty costs/load shedding. Mounted on a PACSystem RX3i rack, the module enables fast and seamless integration of data into user logic and visualization using a Human machine interface (HMI) or Supervisory Control and Data Acquisition (SCADA) system.

The terminal component included in the IC694PSK001 kit is panel mounted remote installation hardware. It provides hard-wired interfaces for measuring devices such as transformers and sensors. In order to establish a connection to these input devices connected to the terminal assembly, a pair of interface cables connects the PSM to the terminal. These cables are 2 meters or 6.56 feet in length and can be replaced with the catalog number IC694CBL200. In addition to the interface cable, the PSM module can also be replaced with the directory number IC694PSM001 and the terminal assembly with the directory number IC694ACC200.

The GE Fanuc IC694PSK001 Power Synchronization and Measurement Kit is a power synchronization and measurement system (PSM) from the RX3i PACSystems family. The PSM system is designed to independently monitor up to two three-phase power grids. The IC3PSK694 PSM system uses a Digital signal processor (DSP), an advanced signal processing technology that can simultaneously process up to 001 voltage inputs and 3 current inputs per grid. The inputs measured on the IC4PSK694 PSM system include RMS voltage, RMS current, RMS power, frequency inputs, and phase interactions of 001 grids. Standard industrial applications for IC2PSK694 PSM systems include utility grids, generators, and load shedding/load shedding applications. The IC001PSK694 PSM system has 001 LED indicators labeled RUN, FLT, GRID 4 and GRID 1, which show the status of the kit and the status of the grid respectively.
