GE IC694MDL754 离散输出模块 支持正逻辑接线配置

【产品详情】

技术规格

额定电压： 12/24 伏直流

# 输出数量： 32 （4 组，每组 8 人）

频率： 不适用

输出电流： 每点 0.75A

输出电压范围： 10.2 至 30V 直流

功耗： 300mA （来自 5V 总线）

IC694MDL754是PACSystem RX3i组件。该模块专门用于三十二 （32） 点离散输出模块，具有两 （2） 组，每组隔离十六 （16） 个输出通道，支持正逻辑接线配置。每个通道设计为提供 10.2 - 20.0 VDC 的输出电压范围，标称电压输出为 12 / 24 VDC，每通道输出电流为 0.75 安培。该模块具有各种电子保护等级，例如短路、过流和过热保护。每个保护功能都支持自动恢复功能。

该IC694MDL754以前由GE智能平台制造，但最近被艾默生自动化收购。此模块占用单个插槽，可以安装到任何远程 I/O 站的本地 CPU 机架的任何空插槽中。它特别兼容与 RX3i CPU 版本 2.90 或更高版本的安装。它设计用于盒式 （IC694TBB032） 或弹簧式 （IC694TBS032） 前接线端子。该模块被归类为带有独立 LED 状态指示灯的低压模块。

该IC694MDL754从背板上的 300 V 总线消耗背板电流为 5 mA（最大值），需要外部电源提供 +12 VDC 至 +30 VDC 电源电压范围，标称电源标称电源为 12/24 VDC。每个通道的最大响应时间为0.5 ms，最大输出漏电流为0.1 mA，典型稳态过流跳闸为每点5安培。该模块的浪涌电流额定值为 3 安培，持续 10 ms，无 ESCP 跳闸。

GE Fanuc IC694MDL754输出模块是用于 RX12i PACSystems PLC 的 24/3 伏直流额定正逻辑输出模块。IC694MDL754输出模块属于 RX3i PACSystems 中端控制器系列。与同类产品中的大多数分立输出模块一样，IC694MDL754输出模块通过其 3 个离散输出点提供 RX32i 控制器和外部输出设备之间的接口。输出分组在 2 个独立的输出组公共中，每个公共组有 16 个输出点。每个输出点都有内置的电子短路和过流保护，每当发生短路或过流情况时，都会生成故障报告并将其发送到RX3i控制器。IC694MDL754输出模块输出可以是正逻辑输出或源出型输出，它们可以将负载切换到电源的正端，同时为负载提供电流。作为标准功能，IC694MDL754输出模块的输出可以在 12 至 24 伏直流（+20% 至 -15%） 范围内切换负载，每个输出点可提供高达 0.75 安培的最大电流。

GE IC694MDL754 离散输出模块 支持正逻辑接线配置

【英文介绍】

Technical specification

Rated voltage: 12/24 V DC

# Output quantity: 32 (4 groups, 8 people per group)

Frequency: Not applicable

Output current: 0.75A per point

Output voltage range: 10.2 to 30V DC

Power consumption: 300mA (from 5V bus)

IC694MDL754 is a PACSystem RX3i component. This module is specifically designed for use in thirty-two (32) point discrete output modules with two (2) groups, each isolating sixteen (16) output channels, supporting positive logic wiring configurations. Each channel is designed to provide an output voltage range of 10.2-20.0 VDC, with a nominal voltage output of 12/24 VDC and an output current of 0.75 amps per channel. The module has various electronic protection levels, such as short circuit, overcurrent and overheat protection. Each protection function supports automatic recovery.

The IC694MDL754 was previously manufactured by GE Intelligent Platforms, but was recently acquired by Emerson Automation. This module occupies a single slot and can be installed into any empty slot of the local CPU rack at any remote I/O station. It is particularly compatible with installations of RX3i CPU version 2.90 or later. It is designed for either box (IC694TBB032) or spring (IC694TBS032) front terminals. The module is classified as a low-voltage module with a separate LED status indicator.

The IC694MDL754 consumes a backplane current of 5 mA (maximum) from the 300 V bus on the backplane and requires an external power supply to provide a power supply voltage range of +12 VDC to +30 VDC, nominal power supply Nominal power supply is 12/24 VDC. The maximum response time per channel is 0.5 ms, the maximum output leakage current is 0.1 mA, and the typical steady-state overcurrent trip is 5 amps per point. The module has a surge current rating of 3 amps, lasts 10 ms, and has no ESCP trip.

The GE Fanuc IC694MDL754 output module is a 24/3V DC rated positive logic output module for RX12i PACSystems PLC. The IC694MDL754 output module belongs to the RX3i PACSystems mid-range controller family. Like most discrete output modules in its class, the IC694MDL754 output module provides an interface between the RX32i controller and external output devices through its three discrete output points. The output group is in 2 separate output group public, each with 16 output points. Each output point has built-in electronic short circuit and overcurrent protection, and whenever a short circuit or overcurrent situation occurs, a fault report is generated and sent to the RX3i controller. The IC694MDL754 output module outputs can be positive logic outputs or sourced-out outputs, which can switch the load to the positive end of the power supply while providing current to the load. As a standard feature, the output of the IC694MDL754 output module can switch loads in the range of 12 to 24 volts DC (+20% to -15%), providing a maximum current of up to 0.75 amps per output point.

GE IC694MDL754 离散输出模块 支持正逻辑接线配置
