GE IC694MDL741 分立输出模块 支持负逻辑接线配置

【产品详情】

技术规格

额定电压： 12/24 伏直流

# 输出数量： 16 （2 组，每组 8 人）

频率： 不适用

输出电流： 每点 0.5 A

输出电压范围： 12 至 24V 直流电（+20%， -15%）

功耗： 110 mA，5V 总线

该IC694MDL741是一个分立输出模块，属于 PACSystem RX3i 可编程自动化控制器 （PAC） 产品系列，该产品系列以前由 GE Intelligent Platforms生产，现在由艾默生自动化制造。该模块具有十六 （16） 个离散输出通道，C。输出通道分为两 （2） 个，每组有八 （8） 个输出通道。该输出模块可用于为继电器线圈、电磁驱动装置、指示灯、电机启动器和类似装置等输出设备供电。该输出模块的每个通道产生 0.5 安培的输出电流，而每组的总电流最大为 2 安培。场到背板、场到帧接地和组到组隔离的光隔离相似，额定值为 250 VAC（连续）和 1500 VAC，持续 1 分钟。输出特性包括 0.5 伏的最大压降;关断状态漏电流为 1 mA;开和关响应时间为 2 毫秒。此模块安装在 RX3i 底板的任何可用插槽中。模块前面板提供单独编号的 LED，指示每个通道的致动状态。它还配有标记为“F”的故障指示器，用于快速识别模块的运行状态。此模块支持安装到 CPU 所在的本地 I/O 机架或作为分布式 I/O 体系结构的一部分。模块插件也随模块一起提供，其中可以编写每个输出通道的简短描述，以便快速识别输出。

GE IC694MDL741 分立输出模块 支持负逻辑接线配置

【英文介绍】

Technical specification

Rated voltage: 12/24 V DC

# Output quantity: 16 (2 groups, 8 people per group)

Frequency: Not applicable

Output current: 0.5A per point

Output voltage range: 12 to 24V DC (+20%, -15%)

Power consumption: 110 mA, 5V bus

The IC694MDL741 is a discrete output module that belongs to the PACSystem RX3i Programmable Automation Controller (PAC) product family, which was previously produced by GE Intelligent Platforms and is now manufactured by Emerson Automation. The module has sixteen (16) discrete output channels and supports a negative logic wiring configuration. The output channels are divided into two (2), each group has eight (8) output channels. The output module can be used to power output devices such as relay coils, electromagnetic drives, indicators, motor starters and similar devices. Each channel of the output module generates an output current of 0.5 amps, while the total current of each group is up to 2 amps. Optical isolation is similar for field-to-backplane, field-to-frame grounding, and group to group isolation, rated at 250 VAC (continuous) and 1500 VAC for 1 minute. Output characteristics include a maximum pressure drop of 0.5 volts; The off state leakage current is 1 mA; The on and off response time is 2 milliseconds. This module is installed in any available slot on the RX3i baseboard. The front panel of the module provides individually numbered leds that indicate the actuation status of each channel. It is also equipped with a fault indicator labeled "F" for quick identification of the operating status of the module. This module supports installation to the local I/O rack where the CPU resides or as part of a distributed I/O architecture. Module plug-ins are also provided with modules, where a short description of each output channel can be written to quickly identify the output.
