IC694MDL654 输入模块 带有正逻辑和负逻辑选项

【产品详情】

技术规格

额定电压： 5 至 12 伏直流电

# 输入数： 32 （4 组，每组 8 人）

频率： 不适用

输入电流： 3 毫安 @ 5 伏直流， 8.5 毫安 @ 12 伏直流

输入电压范围： 0 至 +15V 直流

功耗： 195mA 5V 总线，96mA 用户 5V，272mA 用户 12V

 IC694MDL654输入模块是属于GE发那科自动化公司RX3i PacSystems PLC系列的输入模块。该输入模块带有正逻辑和负逻辑选项，使其能够适应其额定电压范围内的几乎所有PLC应用。该模块带有 32 个输入点，这些输入点隔离在 4 组，每组 8 个输入。这些输入组中的每一个都来源于它们自己与不同设备的连接。GE Fanuc自动化IC694MDL654输入模块的物理特征包括几个LED，用于指示某些输入在特定时刻是否处于活动状态。此设备附带的每个输入都可以在高于 15 伏的电压下工作。

GE Fanuc自动化IC694MDL654输入模块的正面标签上还有一个由蓝色带组成的低压指示器。该模块不包含任何诊断功能或警报，只有一个绿色 LED 指示其是否已通电。该模块与RX3i PLC系统兼容，可以安装在PLC机架的任何插槽中。GE Fanuc 自动化IC694MDL654输入模块的工作电压为 5 至 12 伏直流电，输入电压范围为 0 至 25 伏直流电，输入电流为 3 至 8.5 毫安。该模块的开和关响应时间最长为 1 毫秒，并提供 250 伏交流电的连续隔离电压。该模块的最高工作温度为 60 摄氏度。如果在没有适当通风的情况下暴露在更高的温度下，这可能会缩短模块的使用寿命和整体功能。

IC694MDL654 输入模块 带有正逻辑和负逻辑选项

【英文介绍】

Technical specification

Rated voltage: 5 to 12 volts DC

# Number of inputs: 32 (4 groups, 8 people each)

Frequency: Not applicable

Input current: 3 MA @ 5 V DC, 8.5 MA @ 12 V DC

Input voltage range: 0 to +15V DC

Power consumption: 195mA 5V bus, 96mA user 5V, 272mA user 12V

The IC694MDL654 input module belongs to the GE Fanuc Automation RX3i PacSystems PLC family of input modules. The input module comes with positive and negative logic options, enabling it to be adapted to almost any PLC application in its rated voltage range. The module comes with 32 input points that are isolated in 4 groups of 8 inputs each. Each of these input groups is derived from their own connections to different devices. The physical features of the GE Fanuc Automation IC694MDL654 input module include several leds that indicate whether certain inputs are active at a particular moment. Every input included with this device can operate at voltages higher than 15 volts.

The GE Fanuc Automation IC694MDL654 input module also has a low pressure indicator consisting of a blue band on the front label. The module does not contain any diagnostic functions or alarms, only a green LED indicating whether it is powered on. The module is compatible with the RX3i PLC system and can be installed in any slot of the PLC rack. The GE Fanuc Automation IC694MDL654 input module operates at 5 to 12 volts DC, with input voltages ranging from 0 to 25 volts DC and input currents from 3 to 8.5 MA. The module has an on and off response time of up to 1 millisecond and provides a continuous isolation voltage of 250 volts AC. The maximum operating temperature of the module is 60 degrees Celsius. If exposed to higher temperatures without proper ventilation, this can shorten the service life and overall functionality of the module.

IC694MDL654 输入模块 带有正逻辑和负逻辑选项
