GE IC694MDL632 离散输入 配置为正逻辑或负逻辑

【产品详情】

IC694MDL632是GE Fanuc为PACSystems RX125i系列PLC设计的离散输入，8伏直流，正/负，3点模块。它有 8 个输入，分为两组，每组四个点。这些组中的每一个都可以配置为正逻辑或负逻辑。每个组都有一个单独的公共单元，它们不在模块内部连接。同时打开的最大输入数取决于环境温度。有关详细信息，请参阅手册。

GE RX694i PacSystem 系列的 GE Fanuc IC632MDL3 输入模块的额定电压为 125 伏直流电（正逻辑或负逻辑），输入电压范围为 0 至 150 伏直流电，输入电流额定值为 4.5 毫安（典型值）。IC694MDL632输入模块的额定功耗为背板上的 40 V 总线为 5 毫安，用户输入电源的额定功耗为 36 毫安（典型值）。该模块具有具有以下特性的输入：90 至 150 伏直流之间的导通电压范围、0 至 30 伏直流之间的关断电压范围、3.1 毫安的导通电流、1.1 毫安的关断电流、典型 7 毫秒的“导通”响应时间和 7 毫秒（典型值）的“关断”响应时间。

GE Fanuc IC694MDL632输入模块有 8 个输入点，分为 2 个隔离组，每组有 4 个点。每个组都连接到负逻辑源或正逻辑源。输入的特性使其与输入小工具兼容，包括电子接近开关、按钮和限位开关。现场设备需要用户提供的电源才能高效运行。该模块有 8 个绿色 LED，可显示输入点的开或关状态。该模块是高压模块，由模块顶部的红色带表示。GE Fanuc IC694MDL632输入模块的工作温度范围为 0 至 60 摄氏度（32 至 140 华氏度），存储温度范围为 -40 至 85 摄氏度（-40 至 185 华氏度）。它的非冷凝湿度范围在 5% 到 95% 之间。

GE IC694MDL632 离散输入 配置为正逻辑或负逻辑

【英文介绍】

The IC694MDL632 is a discrete input, 8 V DC, positive/negative, 3 point module designed by GE Fanuc for the PACSystems RX125i series PLC. It has eight inputs, divided into two groups of four points each. Each of these groups can be configured as either positive or negative logic. Each group has a separate common unit that is not connected inside the module. The maximum number of inputs open at the same time depends on the ambient temperature. Refer to the manual for more information.

The GE Fanuc IC632MDL3 input module of the GE RX694i PacSystem series is rated at 125 volts DC (positive or negative logic) with an input voltage range of 0 to 150 volts DC and an input current rating of 4.5 mA (typical value). The rated power consumption of the IC694MDL632 input module is 5 MA for the 40 V bus on the backplane and 36 mA (typical) for the user input power supply. The module has inputs with the following characteristics: an on-voltage range between 90 and 150 volts DC, a turn-off voltage range between 0 and 30 volts DC, a turn-on current of 3.1 mA, a turn-off current of 1.1 mA, a typical "on" response time of 7 ms, and a typical "off" response time of 7 ms.

The GE Fanuc IC694MDL632 input module has 8 input points, divided into 2 isolation groups, each group has 4 points. Each group is connected to a negative logic source or a positive logic source. Input features make it compatible with input gadgets, including electronic proximity switches, buttons, and limit switches. Field equipment requires user-supplied power to operate efficiently. The module has eight green leds that show the on or off status of the input point. The module is a high voltage module, represented by the red band on the top of the module. The GE Fanuc IC694MDL632 input module has an operating temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) and a storage temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). Its non-condensing humidity ranges from 5% to 95%.
