GE IC694MDL231 隔离输入模块 该模块具有开放式架构

【产品详情】

额定电压： 240 伏交流电

# 输入数： 8（隔离）

频率： 50/60赫兹

输入电流： 15毫安

输入电压范围： 0 至 264 伏交流电

功耗： 60 mA，5 V 总线

IC694MDL231输入模块是 240 伏交流额定 RX3i 隔离输入模块。它带有 8 个输入点。该模块由GE Fanuc制造。所有输入点都是隔离的。该模块具有开放式架构，应谨慎处理和安装。因此，输入模块有助于降低PLC系统中的噪音水平。每个输入点都配有一个公共电源输入端子。输入模块中的每个电路都是无功的，并且与各种输入设备、按钮、传感器和开关兼容。模块上的输入点非常灵活。每个单独的模块都可以从外部电源提供电压。请注意，该模块仅适用于交流电源。

输入特性与各种输入设备相匹配，包括按钮、限位开关和电子接近开关。由于这些输入是隔离的，因此每个输入都可以由单独的交流电源供电。用户必须供电才能操作现场设备。此模块需要交流电源，并且与直流电源不兼容。

LED 提供重要信息。八个绿色 LED 指示点 1 到 8 的开/关状态。标签上的红色带子警告用户IC694MDL231是高压的。导通电压为 148-264 VAC，而关断电压为 0-40 VAC。 导通电流最小值为 6mA，关断状态电流最大值为 2.2mA。开/关响应时间最长分别为30ms和45ms。

GE IC694MDL231 隔离输入模块 该模块具有开放式架构

【英文介绍】

Rated voltage: 240 volts AC

# Number of inputs: 8 (isolated)

Frequency: 50/60 Hz

Input current: 15 MA

Input voltage range: 0 to 264 volts AC

Power consumption: 60 mA, 5 V bus

The IC694MDL231 input module is a 240 volt AC rated RX3i isolated input module. It has eight input points. The module is manufactured by GE Fanuc. All input points are isolated. The module has an open architecture and should be handled and installed with care. Therefore, the input module helps to reduce the noise level in the PLC system. Each input point is equipped with a common power input terminal. Each circuit in the input module is reactive and compatible with a variety of input devices, buttons, sensors, and switches. The input points on the module are very flexible. Each individual module can supply voltage from an external power supply. Please note that this module is only suitable for AC power supply.

Input characteristics are matched to various input devices, including buttons, limit switches, and electronic proximity switches. Since these inputs are isolated, each input can be powered by a separate AC power source. Users must supply power to operate field equipment. This module requires AC power and is incompatible with DC power.

Leds provide important information. Eight green leds indicate the on/off status of points 1 to 8. A red band on the label warns users that the IC694MDL231 is high voltage. The on-voltage is 148-264 VAC, while the off voltage is 0-40 VAC. The minimum on-current value is 6mA, and the maximum on-off current value is 2.2mA. The maximum on/off response time is 30ms and 45ms respectively.
