GE IC694BEM320 I/O 链路接口 从属处理器

【产品详情】

模块类型： I/O 链路接口

插槽数量： 1（单插槽）

背板支持： 通用背板

I/O 点： 32 或 64，可滑动跳线

通信端口： （2） RS485/422

发光二极管 好的，RDY

GE Fanuc IC694BEM320 I/O Link Network Interface Module 是 RX3i 产品系列的成员，在 GE Fanuc I/O Link 网络系统中用作从属处理器。一旦安装在网络中，该模块就能够与主设备交换数据，并且根据用户的应用需求，它具有可选择的输入数量，在 32 到 64 之间变化。许多不同类型的主处理器与GE Fanuc IC694BEM320 I / O Link网络接口模块兼容，例如90-30系列和90-70系列的GE Fanuc PLC，PACSystems设备，GE Fanuc系列15,16和18 CNC，C型CNC甚至GE F-D Mate CNC。

可以连接到单个主处理器的 IC694BEM320 I/O Link 网络接口模块的数量没有限制，连接它们的唯一要求是必须有足够的空间用于额外的电源连接来为它们供电。该模块直接由接收系统背板供电，在GE Fanuc的大多数系统中，该电源工作在5伏直流电。GE Fanuc IC2BEM694 I/O Link 网络接口模块前面有 320 个串行通信端口，它们与 RS485 和 RS422 协议兼容。通过使用位于模块盖内的跳线，可以轻松选择要使用的 I/O Link 连接点数量（32 或 64 个输入）。该模块的开放式结构意味着它不应放置在潮湿的地方或暴露在极端高温或低温下。

GE IC694BEM320 I/O 链路接口 从属处理器

【英文介绍】

Module type: I/O link interface

Number of slots: 1 (single slot)

Backplane Support: Universal backplane

I/O point: 32 or 64, sliding jumper

Communication port: (2) RS485/422

Led. All right, RDY

The GE Fanuc IC694BEM320 I/O Link Network Interface Module is a member of the RX3i product family and is used as a slave processor in the GE Fanuc I/O Link network system. Once installed in the network, the module is able to exchange data with the host device, and it has a selectable number of inputs, varying between 32 and 64, depending on the user's application needs. Many different types of main processors are compatible with GE Fanuc IC694BEM320 I/O Link network interface modules, such as GE Fanuc PLCS in the 90-30 series and 90-70 series, PACSystems devices, GE Fanuc Series 15,16 and 18 CNC, and more. C-type CNC or even GE F-D Mate CNC.

There is no limit to the number of IC694BEM320 I/O Link network interface modules that can be connected to a single main processor, and the only requirement for connecting them is that there must be enough space for additional power connections to power them. The module is powered directly from the receiving system backplane, which operates at 5 volts DC in most GE Fanuc systems. The GE Fanuc IC2BEM694 I/O Link network interface module has 320 serial communication ports on the front, which are compatible with the RS485 and RS422 protocols. The number of I/O Link connection points to use (32 or 64 inputs) can be easily selected by using jumpers located inside the module cover. The open construction of the module means that it should not be placed in wet places or exposed to extreme heat or cold.

GE IC694BEM320 I/O 链路接口 从属处理器
