IC660TSD100 GE Fanuc  交流模块

【产品详情】

GE Fanuc IC660TSD100终端组件由GE Fanuc制造。IC660TSD100端子组件与 GE IC660BBD100 和 IC660BBD101 I/O 模块兼容。

IC660TSD100端子组件是GE Fanuc的PLC组件。IC660TSD100端子组件设计用于 IC660BBD100/101 I/O 模块。IC660BBD100 I/O 模块是一个额定电压为 115 伏的交流模块，带有 8 个电路。IC660BBD101 I/O 模块是一个 115 伏交流额定低漏电 I/O 模块，带有 8 个电路。GE Fanuc I/O模块由2个主要部件组成，分别是电子组件和终端组件（如IC660TSD100）。I/O模块的有源组件是电子组件的一部分。可以更改或更换电子组件，而不会对现场接线造成任何干扰。IC660BBD100/101 I/O 模块的所有现场接线连接都连接到IC660TSD100端子组件。此外，模块配置数据存储在EEPROM中，EEPROM是端子组件的一部分。

IC660BBD101 I/O 块重约 4 磅，尺寸约为 8.8 x 3.5 x 3.9 英寸。块到块的隔离额定值为 1500 伏。峰值散热为 16 瓦（8 个输入）和 43.5 瓦（8 个输出），工作电流为 2 安培。单源工作电压范围为 93 至 132 伏交流电。IC660BBD101 I/O 模块支持 47 至 63 赫兹频率。IC660BBD101 I/O 模块上的每个电路都可以配置为输出、输入或三态输入。配置为输出的电路在 2 或 25 摄氏度时分别具有 15 安培 RMS 输出电流、35 安培峰值浪涌电流和 35 或 60 安培峰值块输出电流。对于输出电路，最小阻性推荐负载为 25 毫安，最小推荐感性负载为 40 毫安。IC660BBD101 I/O 模块的工作和存储温度范围分别为 32 到 140 华氏度和 -40 到 212 华氏度。

IC660TSD100 GE Fanuc  交流模块

【英文介绍】

GE Fanuc IC660TSD100 terminal components are manufactured by GE Fanuc. The IC660TSD100 terminal is compatible with the GE IC660BBD100 and IC660BBD101 I/O modules.

The IC660TSD100 terminal assembly is a PLC assembly of GE Fanuc. IC660TSD100 terminal assembly is designed for the IC660BBD100/101 I/O module. The IC660BBD100 I/O module is an AC module rated at 115 volts with 8 circuits. The IC660BBD101 I/O module is a 115 volt AC rated low leakage I/O module with 8 circuits. The GE Fanuc I/O module consists of two main components, namely the electronic component and the terminal component (such as the IC660TSD100). The active component of an I/O module is part of an electronic component. Electronic components can be changed or replaced without any interference with field wiring. All field wiring connections for the IC660BBD100/101 I/O module are connected to the IC660TSD100 terminal assembly. In addition, the module configuration data is stored in the EEPROM, which is part of the terminal assembly.

The IC660BBD101 I/O block weighs about 4 pounds and measures about 8.8 x 3.5 x 3.9 inches. Block to block isolation rating is 1500 volts. Peak heat dissipation is 16 watts (8 inputs) and 43.5 watts (8 outputs) with an operating current of 2 amps. The single-source operating voltage range is 93 to 132 volts AC. The IC660BBD101 I/O module supports frequencies from 47 to 63 Hz. Each circuit on the IC660BBD101 I/O module can be configured as an output, input, or three-state input. Circuits configured for output have 15 amp RMS output current, 35 amp peak surge current, and 35 or 60 amp peak block output current, respectively, at 2 or 25 degrees Celsius. For the output circuit, the minimum resistive recommended load is 25 mA and the minimum inductive load is 40 mA. The IC660BBD101 I/O module operates and stores at temperatures ranging from 32 to 140 degrees Fahrenheit and -40 to 212 degrees Fahrenheit, respectively.

IC660TSD100 GE Fanuc  交流模块
