GE Fanuc IC660TSD021  I/O模块兼容 终端组件

【产品详情】

IC660TSD021终端组件是GE Fanuc终端组件。IC660TSD021终端组件与GE Fanuc IC660BBD021 I/O模块兼容。

GE Fanuc IC660TSD021终端组件是GE Fanuc的I/O块的终端组件，其目录号为IC660BBD021。I/O 模块是一个 24/48 伏直流额定灌电流 I/O 模块，具有 16 个电路。IC660BBD021 I/O 模块的电子组件具有目录号 IC660EBD021，并且与IC660TSD021端子组件兼容。IC660BBD021 I/O模块由GE Fanuc设计，可与3线机电和固态传感器一起使用。IC660BBD021 I/O 模块的诊断功能包括空载检测、开关故障检测、电子短路保护和过热保护。IC660BBD021 I/O 模块的可配置功能包括输出上电默认值、输出脉冲测试功能以及输出保持上一个状态或默认值。IC660BBD021 I/O 模块的建议相对湿度范围为 5% 到 95%。模块及其组件（包括IC660TSD021端子组件）的工作温度范围为 32 至 140 华氏度。

使用 24 伏直流电源时，当输入电压介于 660 和 021 伏直流之间时，IC0BBD8 I/O 块上的每个输入都会打开，而对于 48 伏直流电源，当输入电压介于 0 和 16 伏直流电之间时，每个输入都会打开。使用 24 伏直流电源时，当输入电压介于 660 和 021 伏直流之间时，IC17BBD24 I/O 块上的每个输入关闭，对于 48 伏直流电源，当输入电压介于 34 和 48 伏直流电之间时，每个输入关闭。输入滤波时间可以在 5 到 100 毫秒范围内的任何位置配置。IC660BBD021 I/O 模块及其组件（如IC660TSD021端子组件）可以消耗的最大功率为 300 毫安。但是，典型额定功耗为 150 毫安。IC660BBD021 I/O 块的尺寸为 8.8 x 3.5 x 4.4 英寸。

GE Fanuc IC660TSD021  I/O模块兼容 终端组件

【英文介绍】

The IC660TSD021 terminal component is a GE Fanuc terminal component. The IC660TSD021 terminal component is compatible with the GE Fanuc IC660BBD021 I/O module.

The GE Fanuc IC660TSD021 terminal component is the terminal component of the I/O block of GE Fanuc. The directory number is IC660BBD021. The I/O module is a 24/48 volt DC rated I/O module with 16 circuits. The electronic components of the IC660BBD021 I/O module have the catalog number IC660EBD021 and are compatible with the IC660TSD021 terminal assembly. The IC660BBD021 I/O module is designed by GE Fanuc and can be used with 3-wire electromechanical and solid-state sensors. The diagnostic functions of the IC660BBD021 I/O module include no-load detection, switch fault detection, electronic short-circuit protection and overheat protection. The configurable functions of the IC660BBD021 I/O module include the output power-on default, the output pulse test function, and the output hold the previous state or default. The recommended relative humidity range for the IC660BBD021 I/O module is 5% to 95%. The module and its components, including the IC660TSD021 terminal assembly, operate in a temperature range of 32 to 140 degrees Fahrenheit.

With a 24 volt DC power supply, every input on the IC0BBD8 I/O block is turned on when the input voltage is between 660 and 021 volts DC, and with a 48 volt DC power supply, every input is turned on when the input voltage is between 0 and 16 volts DC. Each input on the IC17BBD24 I/O block is off when the input voltage is between 660 and 021 volts DC with a 24 volt DC power supply, and each input is off when the input voltage is between 34 and 48 volts DC with a 48 volt DC power supply. The input filtering time can be configured anywhere from 5 to 100 milliseconds. The IC660BBD021 I/O module and its components, such as the IC660TSD021 terminal assembly, can consume a maximum power of 300 mA. However, the typical power rating is 150 MA. The IC660BBD021 I/O block measures 8.8 x 3.5 x 4.4 inches.

GE Fanuc IC660TSD021  I/O模块兼容 终端组件
