IC660TSD020 GE Fanuc终端组件 接收器模块

【产品详情】

IC660TSD020终端组件是GE Fanuc终端组件。IC660TSD020端子组件设计用于IC660BBD020块。

GE Fanuc IC660TSD020终端组件是目录号为 IC660BBD020 的 I/O 块的终端组件。与IC660TSD020端子组件兼容的IC660BBD020模块的电子组件具有IC660EBD020目录号。GE Fanuc IC660BBD020 I/O 模块是一个直流供电的 16 电路源/接收器模块，它是一个可配置的 I/O 模块，可以与各种直流执行器和传感器连接。IC660BBD020模块是一个 24/48 伏直流额定源块，可与 3 线固态传感器和机电传感器一起使用。IC16BBD660模块上的 020 个电路中的每一个都可以配置为输入、三态输入或输出。IC660BBD020 I/O 模块所需的典型功率为 150 毫安。块电源电流要求最高可达 300 毫安。

IC660TSD020端子组件及其所属的整个IC660BBD020块的单一电源的工作电压范围为 18 至 56 伏直流电。16 个输出工作电流为 2 安培，该模块的散热为 68.8 瓦。该模块的每个电路都有 LED，用于显示负载侧指示。该块还具有显示块状态的 LED。IC660BBD020模块具有 1.7 毫秒的输入处理时间和 5.6 千欧的输入阻抗。该模块支持以下输入诊断：开路、故障开关和过热诊断。每个电路的稳态输出电流为 2 A。浪涌电流最高可达 10 安培。块输出电流在 15 摄氏度时为 35 安培。在无负载的情况下，建议的最小负载为 50 毫安。GE Fanuc 推荐的IC660TSD020端子组件和整个 I/O 块的工作温度为 0 到 60 摄氏度。

IC660TSD020 GE Fanuc终端组件 接收器模块

【英文介绍】

The IC660TSD020 terminal component is a GE Fanuc terminal component. IC660TSD020 terminal assembly is designed for IC660BBD020 block.

The GE Fanuc IC660TSD020 terminal component is the terminal component of the I/O block whose directory number is IC660BBD020. The electronic components of the IC660BBD020 module that are compatible with the IC660TSD020 terminal assembly have the IC660EBD020 catalog number. The GE Fanuc IC660BBD020 I/O module is a DC-powered 16-circuit source/receiver module that is a configurable I/O module that can be connected to a variety of DC actuators and sensors. The IC660BBD020 module is a 24/48 volt DC rated source block that can be used with 3-wire solid-state sensors and electromechanical sensors. Each of the 020 circuits on the IC16BBD660 module can be configured as input, tri-state input, or output. The typical power required for the IC660BBD020 I/O module is 150 MA. Block power supply current requirements up to 300 MA.

The IC660TSD020 terminal assembly and the single power supply of the entire IC660BBD020 block to which it belongs operate in the voltage range of 18 to 56 volts DC. The 16 outputs operate at 2 amps, and the module's heat dissipation is 68.8 watts. Each circuit of the module has an LED to display the load side indication. The block also has an LED that shows the block status. The IC660BBD020 module has an input processing time of 1.7 ms and an input impedance of 5.6 kilohm. The module supports the following input diagnostics: open circuit, fault switch, and overheat diagnostics. The steady-state output current of each circuit is 2 A. The surge current is up to 10 amps. The block output current is 35 amps at 15 degrees Celsius. In the absence of load, the recommended minimum load is 50 MA. GE Fanuc recommends that the IC660TSD020 terminal assembly and the entire I/O block operate at a temperature of 0 to 60 degrees Celsius.

IC660TSD020 GE Fanuc终端组件 接收器模块
