IC660TSA020 GE DC 模拟 I/O 模块

【产品详情】

GE Fanuc IC660TSA020终端组件是IC660BBA020 I/O 块的终端组件。IC660BBA020 I/O 模块是 DC 模拟 I/O 模块。

GE Fanuc IC660TSA020 终端组件是 GE Fanuc IC660BBA020 I/O 模块的端子组件，它是一个 24/48 伏直流额定模拟 I/O 模块，具有 4 个模拟输入和 2 个输出。此 I/O 模块的电子组件与IC660TSA020端子组件兼容，目录号IC660EBA020。I/O 模块具有 4 个独立的输入电路和 2 个独立的输出电路。此 I/O 模块上的每个电路都可以接受或提供以下 5 个范围之一的信号：0 至 10 伏直流电、-10 至 +10 伏直流电、-5 至 +5 伏直流电、0 至 5 伏直流电和 4 至 20 毫安/1 至 5 伏直流电。电路配置的这种灵活性允许IC660TSA020端子组件和它所属的模拟I/O模块与各种各样的模拟输出和输入设备一起部署。

IC660BBA020 I/O 模块的可配置功能包括每个输出和每个输入的独立缩放、向主机启用和禁用故障报告、可配置的输入滤波时间、每个输入的低限和高报警限值、输入欠量程和超量程检测以及输出欠量程和超量程检测。IC660BBA020 I/O 块应安装在保护外壳内。包含IC660TSA020端子组件的 I/O 块的安装区域应清洁且无空气污染物。I/O 块周围的气流应足以确保环境温度保持在建议的范围内，即 0 到 60 摄氏度。IC660BBA020 I/O 块可以正面朝下或正面朝上安装。相邻 I/O 块之间应提供至少 2 英寸的间距。块上的绿色接地螺钉应使用 12 AWG 电线连接到可靠的接地系统。

IC660TSA020 GE DC 模拟 I/O 模块

【英文介绍】

The GE Fanuc IC660TSA020 terminal component is the terminal component of the IC660BBA020 I/O block. The IC660BBA020 I/O module is a DC analog I/O module.

The GE Fanuc IC660TSA020 terminal assembly is the terminal assembly of the GE Fanuc IC660BBA020 I/O module, which is a 24/48 volt DC rated analog I/O module with 4 analog inputs and 2 outputs. The electronic components of this I/O module are compatible with the IC660TSA020 terminal assembly, directory number IC660EBA020. The I/O module has 4 independent input circuits and 2 independent output circuits. Each circuit on this I/O module can accept or deliver signals in one of five ranges: 0 to 10 volts DC, -10 to +10 volts DC, -5 to +5 volts DC, 0 to 5 volts DC, and 4 to 20 MA /1 to 5 volts DC. This flexibility in circuit configuration allows the IC660TSA020 terminal assembly and the analog I/O module to which it belongs to be deployed with a wide variety of analog output and input devices.

Configurable features of the IC660BBA020 I/O module include independent scaling for each output and each input, enabling and disabling fault reporting to the host, configurable input filtering times, low and high alarm limits for each input, input underrange and overrange detection, and output underrange and overrange detection. The IC660BBA020 I/O block shall be installed in the protective housing. The installation area of the I/O block containing the IC660TSA020 terminal assembly should be clean and free of air contaminants. The airflow around the I/O block should be sufficient to ensure that the ambient temperature remains within the recommended range of 0 to 60 degrees Celsius. The IC660BBA020 I/O block can be mounted face down or face up. A space of at least 2 inches should be provided between adjacent I/O blocks. The green ground screw on the block should be connected to a reliable grounding system using 12 AWG wires.

IC660TSA020 GE DC 模拟 I/O 模块
