GE IC660TBD022 终端组件 具有 16 个离散输入和输出

【产品详情】

 IC660TBD022端子组件是由GE Fanuc制造的Genius I / O组件。该端子组件具有 16 个离散输入和输出，工作在 24 伏直流电。该端子为10%纹波和10毫秒的直流电源压降时间。

IC660TBD022终端组件是由GE发那科设计制造的终端组件。这款 Genius I/O GE 端子组件具有 6 个模拟输入电路，精度为 0.1%。这些电路的报警限值是可编程的，所有故障都由手持监视器和计算机显示，这两者都通常用于编程目的。IC660TBD022终端组件重约1.8公斤，其尺寸包括224毫米（8.8英寸）的高度，88.9毫米（3.5英寸）的宽度和100毫米（3.9英寸）的深度。端子组件在 I/O 模块上包括 LED 信号化，并支持 BSM 控制。该组件的散热额定值最大为 12 瓦。

IC660TBD022终端组件具有诊断功能，其中包括有关输入状态的大量消息。例如，如果电流低于 2 毫安或高警报高于允许的水平，终端将触发一条消息。此端子组件模型需要 93 至 132 伏交流电和 105 至 145 伏直流电范围内的电压。这意味着该装置支持在交流和直流电源下运行。端子组件是电流源输入模块的一部分，具有 10% 的纹波以及 47 至 63 赫兹的频率额定值。IC660TBD022端子组件可以定制系统处理故障的方式。这意味着可以根据要求关闭不同电路的故障报告。但是，即使关闭故障报告选项，有关电路中可能故障的消息也会发送到主机。

GE IC660TBD022 终端组件 具有 16 个离散输入和输出

【英文介绍】

The IC660TBD022 terminal assembly is a Genius I/O assembly manufactured by GE Fanuc. The terminal assembly has 16 discrete inputs and outputs and operates at 24 volts DC. The terminal has a 10% ripple and a 10ms DC supply voltage drop time.

The IC660TBD022 terminal assembly is a terminal assembly designed and manufactured by GE Fanuc. This Genius I/O GE terminal assembly features 6 analog input circuits with an accuracy of 0.1%. The alarm limits of these circuits are programmable, and all faults are displayed by handheld monitors and computers, both of which are commonly used for programming purposes. The IC660TBD022 terminal assembly weighs approximately 1.8 kg and its dimensions include a height of 224 mm (8.8 in), a width of 88.9 mm (3.5 in) and a depth of 100 mm (3.9 in). The terminal assembly includes LED signaling on the I/O module and supports BSM control. The module has a maximum heat dissipation rating of 12 watts.

The IC660TBD022 terminal component has a diagnostic function that includes a large number of messages about the status of the input. For example, if the current is below 2 mah or the high alarm is higher than the allowed level, the terminal will trigger a message. This terminal assembly model requires voltages in the range of 93 to 132 volts AC and 105 to 145 volts DC. This means that the device supports operation on both AC and DC power supplies. The terminal assembly is part of the current source input module with a 10% ripple and a frequency rating of 47 to 63 Hz. The IC660TBD022 terminal assembly can be customized to handle faults. This means that fault reports for different circuits can be turned off on request. However, even if the fault reporting option is turned off, a message about a possible fault in the circuit is sent to the host.

GE IC660TBD022 终端组件 具有 16 个离散输入和输出
