IC660TBA021 RTD输入块端子组件 带有 6 个通道

【产品详情】

IC660TBA021端子组件是由GE Fanuc制造的RTD输入块端子组件。它带有 6 个通道，平均分布在一组中的 2 个电路中。它是一个 24/48 伏直流额定端子组装单元。IC660TBA021终端组件托管的模块的主要功能是监控PLC周围的温度水平。来自模块的输入数据可以以不同的单位发送到PLC的CPU，包括华氏度，摄氏度或计数。该模块中可配置的一些专有功能包括报警阈值、RTD电阻、线性化和输入滤波时间设置。RTD模块中提供自动诊断功能，可检测并指出操作和安装过程中可能发生的不同故障和错误。它可以为用户提供开路、接线错误、输入短路检测、欠量程和超量程诊断。

GE Fanuc IC660TBA021端子组件配备了多路复用器开关，可以轻松转换RTD输入模块和电阻器内部基准之间的输入。此开关可用于自校准。该模块具有噪声抑制功能，如果噪声尖峰超过 4000 伏阈值，则可以阻挡噪声。模块中存在屏蔽端子，以抑制单个电路的噪声。在IC660TBA021端子组件上，有 4 个端子，分别是 SIG、RTN、SHLD 和 REF 端子。这些端子用于输入设备的接线。输入块和端子组件的工作温度范围在0到60摄氏度之间，输入块和端子组件可以在-40到100摄氏度的温度范围内存储。

IC660TBA021 RTD输入块端子组件 带有 6 个通道

【英文介绍】

The IC660TBA021 terminal assembly is an RTD input block terminal assembly manufactured by GE Fanuc. It comes with 6 channels, evenly distributed in 2 circuits in a set. It is a 24/48 volt DC rated terminal assembly unit. The main function of the module hosted by the IC660TBA021 terminal assembly is to monitor the temperature level around the PLC. Input data from the module can be sent to the PLC's CPU in different units, including degrees Fahrenheit, degrees Celsius, or counting. Some of the proprietary features that can be configured in this module include alarm threshold, RTD resistance, linearization, and input filter time Settings. An automatic diagnostic function is provided in the RTD module to detect and point out different faults and errors that may occur during operation and installation. It can provide users with open circuit, wiring error, input short circuit detection, underrange and overrange diagnosis.

The GE Fanuc IC660TBA021 terminal assembly is equipped with a multiplexer switch to easily convert inputs between the RTD input module and the resistor's internal reference. This switch can be used for self-calibration. The module has a noise suppression function that blocks noise if the noise spike exceeds the 4000 volt threshold. There are shielding terminals in the module to suppress the noise of the individual circuits. The IC660TBA021 terminal assembly has four terminals, namely, SIG, RTN, SHLD, and REF terminals. These terminals are used for wiring input devices. The operating temperature range of the input block and terminal assembly is between 0 and 60 degrees Celsius, and the input block and terminal assembly can be stored in the temperature range of -40 to 100 degrees Celsius.

IC660TBA021 RTD输入块端子组件 带有 6 个通道
