IC660MCA512 电源适配器模块 GE

【产品详情】

GE Fanuc IC660MCA512适配器模块是GE手持显示器的电源适配器模块。它由 230 伏交流电源供电。它与GE系列90-30 PLC系统完全兼容。电源适配器的正面有 4 个 LED。当“PWR LED”呈绿色亮起时，表示流入和流出适配器的所有电源都正常工作。如果“PWR LED”关闭，则需要安装外部电池并更换适配器。绿色的“OK LED”表示 CPU 正在运行。还包括一个“电池 LED”，在正常运行期间应保持熄灭状态。当“电池 LED”呈红色亮起时，表示需要更换电池。

IC660MCA512适配器模块配有RS-485端口用于通信。适配器模块所采用的手持式监视器使操作员能够监控 I/O 和通信状态。它支持不同的语言，并且易于使用。显示器具有液晶屏和键盘。键盘具有用于输入输入值和控制命令的不同键。LCD屏幕明亮，可以显示与电流输入，电流输出和故障相关的信息。IC660MCA512适配器模块可以使用位于显示器底部的连接器端口连接到手持显示器。此端口可以容纳显示器的充电器和适配器。监视器使用 HHM 电缆与 PLC 系统中的 I/O 块和其他模块连接。IC660MCA512适配器模块应远离水和发热设备。

IC660MCA512 电源适配器模块 GE

【英文介绍】

The GE Fanuc IC660MCA512 adapter module is a power adapter module for GE handheld displays. It is powered by a 230 volt AC supply. It is fully compatible with GE series 90-30 PLC systems. There are 4 leds on the front of the power adapter. When the PWR LED lights up green, it means that all power supplies to and from the adapter are working properly. If the PWR LED is off, you need to install an external battery and replace the adapter. A green "OK LED" indicates that the CPU is running. Also included is a "battery LED" that should remain off during normal operation. When the "battery LED" lights up red, it means that the battery needs to be replaced.

The IC660MCA512 adapter module is equipped with an RS-485 port for communication. The handheld monitor in the adapter module enables the operator to monitor I/O and communication status. It supports different languages and is easy to use. The monitor has a LCD screen and a keyboard. The keyboard has different keys for entering input values and control commands. The LCD screen is bright and can display information related to current input, current output and fault. The IC660MCA512 adapter module can be connected to a handheld display using a connector port located at the bottom of the display. This port can accommodate chargers and adapters for the monitor. The monitor uses HHM cables to connect to I/O blocks and other modules in the PLC system. The IC660MCA512 adapter module should be kept away from water and heating devices.

IC660MCA512 电源适配器模块 GE
