IC660HHC005 通信电缆  I/O 通信端口

【产品详情】

IC660HHC005是与目录号为IC660HHM501的手持显示器一起使用的通信电缆。这两种产品都设计用于建立与Genius IO块的通信，以进行参数配置，监控，诊断和故障排除。这些产品以前由GE Fanuc Automation制造，目前隶属于艾默生自动化。沿 HHM 设备的此电缆是已停产的产品。IC660HHC005是一根盘绕的、柔性的黑色电缆。电缆的一端连接到手持显示器左侧顶部的通信端口，而另一端连接器直接安装在第一个终端之前位于 I/O 块端子顶部的块 I/O 通信端口。IC660HHC005支持通信速率，例如 153.6 Kbaud 标准、153.5 Kbaud 扩展、76.8 Kbaud、38.4 Kbaud。完全拉伸时的最大电缆距离为 5 英尺或 1.5 米，重 2 磅。它兼容所有天才I/O模块以及五系列天才总线控制器，90-70系列天才总线控制器，带诊断功能的六系列天才总线控制器，不带诊断的六系列天才总线控制器，90-30系列GENIUS通信模块，GENIUS网络接口（GENI）模块，IBM PC接口模块（PCIM），带倒置连接器的GENIUS网络接口（GENI）模块， 90-70 系列远程 I/O 扫描仪、24/48VDC 总线交换模块 （BSM）、115VAC/125VDC 总线交换模块 （BSM） 和所有现场控制产品。IC660HHC005可以随时连接和断开目标模块的 9 针 D-shell 手持监视器接口，而不会中断 genious I/O 网络，但是，在插入和断开电缆连接器时必须小心防止产生振动和冲击。

IC660HHC005手持显示器电缆属于GE Fanuc Genius I/O系列I/O模块及配件。它是一种可拆卸的塑料盘绕通信电缆，可用于与Genius手持显示器（HHM）和Genius I / O模块进行通信。此黑色电缆设计用于IC660HHM501手持显示器。它长 5 英尺，重 2 磅。该模块的通信数据速率为标准 153.6 kbaud，扩展为 153.5 kbaud。它可用于从使用手持监视器的GE系列90-70，系列六和系列五PLC中的特定内存位置读取数据。IC660HHC005电缆的一端可以连接到 HHM，另一端必须连接到 Genius I/O 模块或总线连接器。

IC660HHC005手持式显示器电缆设计用于轻松连接到Genius I/O模块。它还具有使用充分端接的串行总线在线或离线配置模块的功能。这种盘绕电缆为正确通信提供了电气路径。如果用户必须将新设备添加到现有系统或总线，则必须脱机配置模块。在在线配置期间，必须只有一个手持监视器与串行总线连接，以自动检测参考地址，而不会与其他设备和PLC冲突。如果用户需要使用金属安装支架将显示器安装在面板后面，则必须在面板中布置一个切口，并在 HHM 通信电缆的范围内安装显示器连接器。该连接器有助于永久安装 HHM，并且具有用于总线电缆的端子和手持显示器的盘绕通信电缆。

IC660HHC005 通信电缆  I/O 通信端口

【英文介绍】

IC660HHC005 is a communication cable used with a handheld display with catalog number IC660HHM501. Both products are designed to establish communication with the Genius IO block for parameter configuration, monitoring, diagnosis, and troubleshooting. These products were previously manufactured by GE Fanuc Automation and are currently owned by Emerson Automation. This cable along HHM equipment is a discontinued product. The IC660HHC005 is a coiled, flexible black cable. One end of the cable is connected to the communication port on the top left side of the handheld display, while the other end connector is installed directly on the block I/O communication port located on top of the I/O block terminal before the first terminal. The IC660HHC005 supports communication rates, such as 153.6 Kbaud standard, 153.5 Kbaud extended, 76.8 Kbaud, and 38.4 Kbaud. The maximum cable distance when fully stretched is 5 feet or 1.5 meters and weighs 2 pounds. It is compatible with all GENIUS I/O modules as well as five series GENIUS Bus controllers, 90-70 series Genius Bus controllers, six series Genius Bus controllers with diagnostic functions, six series Genius Bus controllers without diagnostics, 90-30 series Genius communication modules, GENIUS Network Interface (GENI) modules, and more. IBM PC Interface Module (PCIM), GENIUS Network Interface (GENI) module with Inverted connector, The 90-70 series remote I/O scanner, 24/48VDC Bus Switch Module (BSM), 115VAC/125VDC Bus Switch Module (BSM) and all field control products. The IC660HHC005 can connect and disconnect the 9-pin D-shell handheld monitor interface of the target module at any time without interrupting the genious I/O network, however, care must be taken to prevent vibration and shock when inserting and disconnecting cable connectors.

The IC660HHC005 Handheld display cable belongs to the GE Fanuc Genius I/O series I/O modules and accessories. It is a detachable plastic coil communication cable that can be used to communicate with Genius Handheld displays (HHM) and Genius I/O modules. This black cable is designed for IC660HHM501 handheld display. It is five feet long and weighs two pounds. The communication data rate of the module is standard 153.6kbaud, extended to 153.5kbaud. It can be used to read data from specific memory locations in GE Series 90-70, Series Six and Series five PLCS using handheld monitors. One end of the IC660HHC005 cable can be connected to the HHM, and the other end must be connected to the Genius I/O module or bus connector.

The IC660HHC005 handheld display cable is designed for easy connection to the Genius I/O module. It also has the ability to configure modules online or offline using a fully terminated serial bus. This coiled cable provides the electrical path for proper communication. If a user must add a new device to an existing system or bus, the module must be configured offline. During online configuration, only one handheld monitor must be connected to the serial bus to automatically detect reference addresses without conflicting with other devices and PLCS. If the user needs to mount the display behind the panel using a metal mounting bracket, a notch must be laid out in the panel and the display connector installed within the range of the HHM communication cable. The connector facilitates permanent installation of HHM and has terminals for bus cables and coiled communication cables for handheld displays.
