IC660EBD101 输出模块 I/O 模块  承载提供模块功能

【产品详情】

IC660EBD101是IC660BBD101八 （8） 电路 115 VAC 组合输入和输出模块 I/O 模块的组件。该IC660BBD101专门用于电子装配模块，可用作现有IC660BBD101安装的替换组件。该电子组件组件承载提供模块功能的必要电路。IC660EBD101是组合I/O模块必不可少的，其通道可配置为输入或输出。该组件可用的输入和输出通道额定值为 115 VAC，输入通道接受 6 mA 的输入电流，而每个输出通道能够产生 2 A 的最大电流。此电子组件需要使用目录号为 IC660TSD101 的端子底座。IC660EBD101电子组件的主要组件包括金属氧化物压敏电阻（MOV）、.1 μF电容、内部智能开关以及模块每个通道的LED状态指示灯。该组件还负责执行与主机控制器的数据交换以及与外部电源的连接。该IC660EBD101能够确定过热、短路情况、开路检测、空载诊断、过载诊断和开关故障诊断。该组件支持非三态和三态输入的接线，而输出电路支持源配置。该电子组件还配有内部安装的开关，用于模块保护。该组件的温度要求包括0至60摄氏度的工作温度，-40摄氏度至100摄氏度的存储温度，相对湿度为5-95%。

GE Fanuc IC660EBD101电子组件是GE智能平台/GE Fanuc Automation的产品。它属于Genius I / O模块系列，它有8个由输入和输出组成的电路。该块的尺寸约为 8.83 x 3.50 x 3.94 英寸，重量约为 4 磅。它还具有 I/O 启用和单元确定 LED，以及开关逻辑侧每个电路上的 LED 指示灯，以及 1500 V 块到块隔离电压额定值，16 个输入时具有 8 瓦的散热功率，或 43 瓦的散热功率，8 个输出，额定电流为 2 安培。所有模块输入和输出关闭的待机功率为 8.5 瓦，IC660EBD101电子组件模块配备 93 至 132 伏交流单源工作电压，频率范围为 47 至 63 赫兹。

IC660EBD101电子装配模块的其他规格包括 0 至 60 摄氏度的工作温度范围和 -40 至 100 摄氏度的存储温度范围。该模块的振动额定值为 5 至 10 赫兹，可承受 5% 至 95% 的非冷凝湿度。GE Fanuc IC660EBD101电子装配模块有 8 个电路，以隔离组排列，额定电压为 115 伏交流电标称值。当任何电路配置为输入时，该电路的LED指示灯显示输入端子上的阈值电压。另一方面，当任何电路配置为输出时，指示器显示CPU命令的条件。

IC660EBD101 输出模块 I/O 模块  承载提供模块功能

【英文介绍】

The IC660EBD101 is a component of the IC660BBD101 eight (8) circuit 115 VAC combined input and output module I/O module. The IC660BBD101 is specifically designed for electronic assembly modules and can be used as a replacement component for existing IC660BBD101 installations. The electronic component assembly contains the circuits necessary to provide the function of the module. The IC660EBD101 is essential for a combined I/O module with a channel that can be configured as an input or output. The available input and output channels are rated at 115 VAC, the input channels accept 6 mA of input current, and each output channel is capable of generating A maximum current of 2 A. This electronic component requires a terminal base with directory number IC660TSD101. The main components of the IC660EBD101 electronics assembly include metal oxide varistor (MOV), a.1μf capacitor, internal smart switches, and LED status indicators for each channel of the module. This component is also responsible for performing the data exchange with the host controller and the connection to the external power supply. The IC660EBD101 is capable of determining overheat, short circuit conditions, open circuit detection, no-load diagnosis, overload diagnosis, and switch fault diagnosis. The component supports wiring for both non-tri-state and tri-state inputs, while the output circuit supports the source configuration. The electronic assembly is also equipped with an internally mounted switch for module protection. The temperature requirements for this component include an operating temperature of 0 to 60 degrees Celsius, a storage temperature of -40 to 100 degrees Celsius, and a relative humidity of 5-95%.

The GE Fanuc IC660EBD101 electronic assembly is a product of GE Intelligent Platform /GE Fanuc Automation. It belongs to the Genius I/O module family and it has 8 circuits composed of input and output. The block measures about 8.83 x 3.50 x 3.94 inches and weighs about 4 pounds. It also features I/O enabled and unit determination leds, as well as LED indicators on each circuit on the switching logic side, and a 1500 V block-to-block isolation voltage rating with 8 watts of heat dissipation power at 16 inputs, or 43 watts of heat dissipation power, and 8 outputs with a current rating of 2 amps. Standby power with all modules input and output off is 8.5 watts, and the IC660EBD101 electronic component module is equipped with a single-source operating voltage of 93 to 132 volts AC in a frequency range of 47 to 63 Hz.

Additional specifications for the IC660EBD101 electronic assembly module include an operating temperature range of 0 to 60 degrees Celsius and a storage temperature range of -40 to 100 degrees Celsius. The module has a vibration rating of 5 to 10 Hz and can withstand 5 to 95 percent non-condensing humidity. The GE Fanuc IC660EBD101 electronic assembly module has 8 circuits arranged in isolation groups with a rated voltage of 115 volts AC nominal. When any circuit is configured as an input, the LED indicator of that circuit displays the threshold voltage on the input terminal. On the other hand, when any circuit is configured as an output, the indicator shows the condition of the CPU command.
