UR7KH GE 通信模块 安装在通用继电器

【产品详情】

通用电气Multilin的UR-7KH是一种通信模块，旨在安装在通用继电器系列中。它支持与其他优傲单元的继电器间通信，取代了特别昂贵的传统铜缆硬接线。此版本的模块为继电器提供两个通信通道，均为 1300 nm、单模、LASER 通道。

模块提供的通信通道允许快速安全地传输信息。继电器能够监控系统的通道并检查系统运行状况。诊断数据可以在 EnerVista UR 中显示、趋势分析和导出，EnerVista UR 是 Multilini 与通用继电器系列兼容的行业领先软件。

UR-7KH模块由通用电气生产，因此具有大量的软件支持和交叉继电器兼容性。该模块有大量的修订，通用电气定期更新他们的手册、数据表和常见问题解答，以使用户尽可能保持最新状态。修订会自动上传到 EnerVista 软件，该软件位于 EnerVista 集成商套件中。

关于 UR-7KH 的常见问题

UR-7KH Multilin GE UR 系列通用继电器的通信特点是什么？

UR-7KH是用于Multilin通用继电器的通信模块（通信模块）。UR-7KH是7型通信模块的7K变体。并非所有变体都可以在特定的通用继电器中找到。请务必查阅每个 Mutlilin 通用继电器提供的订购选项，以了解该特定继电器的可变选项的全面视图。例如，UR-7KH 可能出现在 T60 变压器保护系统中。T2 产品目录第 60 章中有特定的订货号表，显示了继电器系统中可以包含哪些 7 型通信模块。7K 订购号表示具有 1300 nm 激光波长的双通道单模模块。7K COMMS 模块的配置方式与 73 模块、72 模块和 7D 光纤激光器模块相同，具有两个通道。第一个通道以垂直方向在第二个通道上定向。第一个通道具有 Tx1 和 Rx1 部分，第二个通道在激光光纤模块内具有 Tx2 和 Rx2 选项。

UR7KH GE 通信模块 安装在通用继电器

【英文介绍】

The UR-7IH from GE Multilin is a module in the general purpose relay family that provides a communication channel between two relays. These channels are LED-based and operate at 1300 nm. Channels are multimode, not single-mode.

These modules are easy to install and require only a few considerations to complete a short process to ensure that the process goes smoothly:

Unplug the control power from the relay to eliminate the risk of injury, misoperation, or system damage. After sliding the latch up or unscrewing the screw (depending on the universal relay), open the panel to the left for easy access to the module carrier.

Pull the ejector clip at the same time to release the module from its fixed position. Gently slide the module out of the slot while marking the slot on the paper; New modules must be placed in the same slot because modules can only be replaced with similar modules.

Insert the new module smoothly and engage the ejector clip at the same time to secure the relay into its slot. The plug and play function of the module enables it to start operating as soon as the control power is restored.

Multilin's simplified module installation process reduces relay downtime and completely eliminates the lengthy software installation process.

Frequently Asked Questions about UR-7IH

Ur-7ih Communication Module Do GE Dorin UR Series universal relays have LED components for communication functions?

The UR-7IH communication module is used in certain general-purpose relay systems, such as the B30 bus differential system and the L90, which is a line differential relay. In either case, the UR-7IH communication module provides communication functions for general-purpose relays. The UR-7IH communication module GE in particular has the feature of using the 7I ordering number selection. There are several different ordering code options. In the B30 Bus Differential System catalog, users can choose from 2B, 2I, 2J, 7A, 7B, 7C, 7H, 7I, 7J, 7S, 7W and 77 ordering options. Each order option allows the COMMS module to have variable functionality. The 7I ordering number (which can be found in the UR-7IH COMMS module) features a 1300 nm multi-mode LED with two channels.

How many channels does the COMMS module usually have in UR Series Universal Multilin relays?

COMMS modules may come with different channels, depending on the particular subscription number at hand. For example, the UR-7IH communication module GE has two channels. Typically, COMMS modules range between 1 or 2 channels, and in some cases may be LED, ELED, or have laser components.
