MMII-C-0-0-120 单元是电机管理器II系列 GE

【产品详情】

MMII-C-0-0-120由通用电气Multilin生产。该单元是电机管理器II系列的一部分，该系列是一组低压电机控制模块。这些单元旨在为电机系统提供先进的保护和控制。这些型号还具有紧凑的尺寸，可与可能具有该型号部分或全部相同功能的类似型号相媲美。

MMII-C-0-0-120单元旨在提供处理任何电压过载或相位不平衡等功能。如果任何接触器发生故障或转子锁定和/或停止，则此型号能够覆盖它们。该单元还内置了集成了热绕组热敏电阻电路。

MMII-C-0-0-120 模块实现最佳功能所需的功率水平为 250 伏交流电（标称值）。该装置具有备用容量，以防电压无法达到最佳摄入量。如果确实发生这种情况，则欠压自动重启将启动以解决问题。

本机内置大量I/O端口;此模块上最多有 20 个 I/O 端口。其中 4 个是输出端口：一对接触器端口和一对可编程输出端口。其余 16 个端口是输入端口，其中 6 个是固定端口，其余 10 个是可编程输入端口。该型号不包括该系列其他一些单元中包含的选件包，由型号中的两个零表示。

MMII-C-0-0-120 单元是电机管理器II系列 GE

【英文介绍】

The MMI-C-0-0-120 is manufactured by General Electric Multilin. The unit is part of the Motor Manager II series, a group of low-voltage motor control modules. These units are designed to provide advanced protection and control for motor systems. These models also have compact dimensions that are comparable to similar models that may have some or all of the same features as this model.

The MMI-C-0-0-120 unit is designed to provide functions such as handling any voltage overload or phase imbalance. This model is capable of covering any of the contactors if they fail or the rotor locks and/or stops. The unit is also built with an integrated thermal winding thermistor circuit.

The power level required for the MMI-C-0-0-120 module to achieve optimal functionality is 250 volts AC (nominal value). The unit has a backup capacity in case the voltage does not reach the optimal intake. If this does happen, an undervoltage automatic restart will be activated to resolve the problem.

A large number of built-in I/O ports; There are up to 20 I/O ports on this module. Four of them are output ports: a pair of contactor ports and a pair of programmable output ports. The remaining 16 ports are input ports, of which 6 are fixed ports and the remaining 10 are programmable input ports. This model does not include the option package included in some of the other units in the series, which is represented by two zeros in the model number.
