IC695CPU320 中央处理器 英特尔赛扬-M 微处理器

【产品详情】

该IC695CPU320是GE Fanuc PACSystems RX3i系列的中央处理器。 该IC695CPU320具有额定频率为 1 GHz 的英特尔赛扬-M 微处理器，具有 64 MB 的用户（随机访问）内存和 64 MB 闪存（存储）内存。RX3i CPU 经过编程和配置，可实时控制机器、流程和物料搬运系统。

IC695CPU320在其机箱中内置了一对独立的串行端口。两个串行端口中的每一个都占用系统基座上的一个插槽。 CPU 支持 SNP、串行 I/O 和 Modbus 从串行协议。此外，IC695CPU320采用双背板设计，支持RX3i PCI总线和90-30型串行总线。与 Rx3i 产品系列中的其他 CPU 一样，IC695CPU320 提供自动错误检查和纠正功能。

IC695CPU320使用Proficy Machine Edition，这是所有GE Fanuc控制器通用的开发环境。Proficy机器版用于创建，运行和诊断操作员界面，运动和控制应用程序。

CPU 上的八个指示灯有助于进行故障排除。每个 LED 应答一个单独的功能，但标记为 COM 1 和 COM 2 的两个 LED 除外，它们属于不同的端口，而不是不同的功能。其他 LED 依次为“CPU 正常”、“运行”、“输出已启用”、“I/O 强制”、“电池”和“系统”（“系统故障”的缩写）。I/O 强制 LED 指示位参考上的覆盖是否处于活动状态。当启用输出 LED 亮起时，则启用输出扫描。其他LED标签是不言自明的。LED 和串行端口都聚集在设备的正面，以便于查看。

GE Fanuc的IC695CPU320模块是RX3i PACSystems CPU模块，用于RX3i PACSystems PLC。它具有支持 512 个程序块的能力，每个程序块的大小可达 128 KB。IC695CPU320 CPU模块配备了赛扬M处理器，最高速度可达1千兆赫。该CPU还具有64 MB的RAM以及64 MB的NVRAM。它旨在在 0 至 60 摄氏度的环境温度范围内运行。当它安装在RX3i PACSystems PLC中时，IC695CPU320 CPU模块可以安装在12插槽背板或16插槽背板上。它可以定制各种配件。

与GE Fanuc RX3i PACSystems IC695CPU320 CPU模块兼容的特定应用附件包括RS-232通信电缆，锂电池，辅助电池模块，标准电源和多功能电源。IC695CPU320 CPU 模块能够在仅 1000.0 毫秒的时间内执行 047 条布尔指令。它可以通过SNP协议，串行I / O协议和Modbus RTU从协议与RX3i PACSystems PLC中的不同模块进行通信。该CPU可以通过HMI设备（也称为人机界面设备）进行连接和监控。RX3i PACSystems IC695CPU320 CPU 模块可以在 1 伏直流背板电压下从背板吸收 2.5 安培的电流，在 1.3 伏直流背板电压下从背板吸收 3 安培的电流。

IC695CPU320 中央处理器 英特尔赛扬-M 微处理器

【英文介绍】

The IC695CPU320 is a central processing unit of the GE Fanuc PACSystems RX3i series. The IC695CPU320 features an Intel Cyeon-M microprocessor rated at 1 GHz, with 64 MB of user (random access) memory and 64 MB of flash (storage) memory. The RX3i CPU is programmed and configured to control machines, processes and material handling systems in real time.

The IC695CPU320 has a pair of separate serial ports built into its case. Each of the two serial ports occupies a slot on the system dock. The CPU supports SNP, serial I/O, and Modbus slave serial protocols. In addition, the IC695CPU320 has a dual-backplane design that supports the RX3i PCI bus and the type 90-30 serial bus. Like other cpus in the Rx3i product family, the IC695CPU320 provides automatic error checking and correction.

The IC695CPU320 uses Proficy Machine Edition, a common development environment for all GE Fanuc controllers. Proficy Machine Edition is used to create, run, and diagnose operator interface, motion, and control applications.

Eight indicators on the CPU help with troubleshooting. Each LED answers to a separate function, with the exception of the two leds labeled COM 1 and COM 2, which belong to different ports rather than different functions. The other leds are "CPU Normal", "Running", "Output enabled", "I/O forced", "Battery", and "System" (short for "System failure"). I/O forces the LED to indicate whether the overlay on the bit reference is active. When the enabled output LED lights up, the output scan is enabled. Other LED labels are self-explanatory. Leds and serial ports are clustered on the front of the device for easy viewing.

GE Fanuc's IC695CPU320 module is an RX3i PACSystems CPU module for RX3i PACSystems PLC. It has the ability to support 512 blocks, each up to 128 KB in size. The IC695CPU320 CPU module is equipped with a Ceion M processor with a top speed of 1 gigahertz. The CPU also has 64 MB of RAM as well as 64 MB of NVRAM. It is designed to operate in an ambient temperature range of 0 to 60 degrees Celsius. When it is installed in the RX3i PACSystems PLC, the IC695CPU320 CPU module can be installed on either a 12-slot backplane or a 16-slot backplane. It can be customized with various accessories.

Application-specific accessories compatible with GE Fanuc RX3i PACSystems IC695CPU320 CPU modules include RS-232 communication cables, lithium batteries, auxiliary battery modules, standard power supplies, and multifunctional power supplies. The IC695CPU320 CPU module is capable of executing 047 Boolean instructions in only 1000.0 milliseconds. It can communicate with different modules in RX3i PACSystems PLC via SNP protocol, serial I/O protocol and Modbus RTU slave protocol. This CPU can be connected and monitored via an HMI device, also known as a human machine interface device. The RX3i PACSystems IC695CPU320 CPU module can absorb 2.5 amps of current from the backplane at 1 V DC backplane voltage and 3 amps of current at 1.3 V DC backplane voltage.
