IC693CPU352 单插槽CPU模块 GE  用户程序存储器

【产品详情】

产品描述

IC693CPU352是GE自动化和控制公司为90/30系列PLC系统制造的单插槽CPU模块。 每个系统的底板总数为 8，其中包括一个用于 CPU 的底板，以及 890 个远程和扩展基板。电源的负载要求为5mA，采用+80386V直流电源供电。处理器类型为25EX，处理速度为0Mhz。系统的最佳工作温度在 60 度到 32 摄氏度（140 华氏度到 0 华氏度）之间。此规范也称为环境温度。每 22K 逻辑（即布尔触点）的典型扫描速率为 1.<> 毫秒。

自版本 9.0 固件发布以来，用户的最大程序内存为 240K 字节。但是，用户程序存储器的有效可用大小取决于可配置类型的字存储器的配置量。离散输入点和输出点各为 2048 位，内部线圈为 4096 位，全局存储器为 1280 位，临时输出线圈为 256 位，总共 128 位（%S、%SB、%SA、%SC，每个有 32 位）作为系统状态的参考。有%R（寄存器存储器），%AI（模拟输入），%AQ（模拟输出），所有这些都可以以128字的增量进行配置。

有超过2000个计时器/计数器，并且还有移位寄存器。内置三个串行端口，支持RTU从机和SNP或SNPX从机，以及SNP或SNPX主站或从站，以及串行输入/输出（在端口1和端口2上）。通信支持局域网（支持多点）、以太网、Profibus、FIP、GBC、GCM+ 选件模块。闪存和 RAM 是可用的存储内存类型。Logicmaster 配置和编程软件支持 CPU352。

技术规格

处理器速度 ： 25兆赫

I/O 点 ： 2048

寄存器存储器 ： 240千字节

浮点数学： 是的

32 位系统

处理器： 80386EX

GE Fanuc的IC693CPU352 CPU是90-30系列CPU模块。它设计用于 90-30 系列产品线的可编程逻辑控制器或 PLC 的中心。在90-30系列PLC中，IC693CPU352 CPU模块安装在特殊的CPU底板上，PLC可以包含多达7个额外的底板，这些基板是远程底板或扩展底板。IC693CPU352 CPU 模块的电压输入额定值为 5 伏直流电，而其额定电流为 910 毫安。此 CPU 的最大处理器速度为 25 兆赫兹。IC693CPU352 CPU 模块可以在 32 到 140 华氏度或 0 到 60 摄氏度的温度范围内全功率运行。

GE Fanuc 系列 90-30 IC693CPU352 CPU 模块自带 3 个串行端口用于通信，它支持 RTU 从机协议、SNP 从机协议和 SNPX 从机协议。该CPU在运行过程中散发约4.55瓦的热量。选件模块可以连接到IC693CPU352 CPU模块，以允许它通过不同的网络进行通信。这些选件模块包括 Profibus、以太网、FIP、GBC、GCM+ 和多点 LAN 模块。IC693CPU352 CPU 模块能够大约每 1.0 毫秒扫描 22 KB 的逻辑。CPU模块底部有一个屏蔽接地连接器，可以保护它。IC693CPU352 CPU模块支持的操作模式是运行模式和停止模式，用户可以通过按键开关选择他们想要的模式。

IC693CPU352 单插槽CPU模块 GE  用户程序存储器

【英文介绍】

Product description

The IC693CPU352 is a single socket CPU module manufactured by GE Automation and Controls for the 90/30 series PLC system. Each system has a total of eight backboards, including one for the CPU, and 890 remote and expansion baseboards. The load requirement of the power supply is 5mA, and the power supply is +80386V DC. The processor type is 25EX and the processing speed is 0Mhz. The optimal operating temperature of the system is between 60 degrees and 32 degrees Celsius (140 degrees and 0 degrees Fahrenheit). This specification is also called ambient temperature. The typical scan rate per 22K logic (i.e., Boolean contacts) is 1.<> ms.

Since the release of version 9.0 firmware, the maximum program memory for users is 240K bytes. However, the effective available size of user program memory depends on the amount of configurable word memory of the configurable type. The discrete input and output points are 2048 bits each, the internal coil is 4096 bits, the global memory is 1280 bits, and the temporary output coil is 256 bits, for a total of 128 bits (%S, %SB, %SA, %SC, each with 32 bits) as a reference to the state of the system. There are %R (register memory), %AI (analog input), %AQ (analog output), all of which can be configured in 128-word increments.

There are over 2000 timers/counters, and there are shift registers. Three built-in serial ports support RTU slave and SNP or SNPX slave, SNP or SNPX master or slave, and serial input/output (on ports 1 and 2). Communication support LAN (multi-point support), Ethernet, Profibus, FIP, GBC, GCM+ optional modules. Flash and RAM are the types of storage memory available. The Logicmaster configuration and programming software supports CPU352.

Technical specification

Processor speed: 25 MHZ

I/O point: 2048

Register memory: 240 kilobytes

Floating point math: Yes

32-bit system

Processor: 80386EX

GE Fanuc's IC693CPU352 CPU is a 90-30 series CPU module. It is designed for use in the center of a programmable logic controller or PLC for the 90-30 series product line. In the 90-30 series PLC, the IC693CPU352 CPU module is installed on a special CPU baseboard, and the PLC can contain up to 7 additional baseboards, which are remote baseboards or expansion baseboards. The IC693CPU352 CPU module has a voltage input rating of 5 volts DC, while its current rating is 910 mA. This CPU has a maximum processor speed of 25 megahertz. The IC693CPU352 CPU module can operate at full power in the temperature range of 32 to 140 degrees Fahrenheit or 0 to 60 degrees Celsius.

GE Fanuc Series 90-30 IC693CPU352 CPU module comes with 3 serial ports for communication, it supports RTU slave protocol, SNP slave protocol and SNPX slave protocol. The CPU emits about 4.55 watts of heat during operation. The option module can be connected to the IC693CPU352 CPU module to allow it to communicate over different networks. These optional modules include Profibus, Ethernet, FIP, GBC, GCM+, and multipoint LAN modules. The IC693CPU352 CPU module is capable of scanning 22 KB of logic approximately every 1.0 ms. The CPU module has a shielded ground connector on the bottom that protects it. The operation mode supported by IC693CPU352 CPU module is run mode and stop mode, and users can select the mode they want through the key switch.
