IC693CPU341 GE 单插槽CPU 模块化硬件类型

【产品详情】

IC693CPU341是一个单插槽CPU，以前由GE Fanuc Automation制造，现在隶属于艾默生自动化。该 CPU 是 80C188XL、20 MHz 处理器，布尔执行速度为每 0K 逻辑（布尔触点）3.1 毫秒。它属于模块化硬件类型，内置用户存储器总计 80 KB，支持多达 512 个离散输入、512 个离散输出、1024 个模拟输入字和 256 个模拟输出。此外，IC693CPU341还内置了 1280 位离散全局内存 （%G）;1024 位内部线圈 （%M）;256位输出（临时）线圈（%T）;128 位系统状态参考（%S、%SA、%SB、%SC，每个内存区域各有 32 位和 9999 个寄存器内存字 （%R）。该 CPU 有 2000 多个定时器可用，并支持移位寄存器、中断和超控指令。它具有电池备份时钟，并与PCM / CCM存储器兼容。IC693CPU341不附带嵌入式存储器，而是支持SNP和SNP-X协议的串行通信端口由电源模块托管。此外，IC693CPU341支持的可选通信模块包括以太网、FIP、Profibus、GBC、GCM 和 GCM+ 选件模块。该IC693CPU341支持配置多达 5 个底板，其中包括 1 个 CPU 底板和四 （4） 个扩展和/或远程 I/O 底板。该 CPU 需要 490 VDC 电源提供 5 mA 电流，而工作温度要求为 0 至 60 摄氏度或 32 至 140 华氏度。

IC693CPU341模块是时钟频率为20兆赫的GE Fanuc CPU模块。IC693CPU341模块专为 90-30 系列可编程逻辑控制器而设计和开发。IC693CPU341模块上提供的用户存储器为 80 KB。该模块的早期版本支持RAM和可选的EPROM或EEPROM。从硬件版本 IC693CPU341-J 和固件版本 4.61 开始，此 CPU 模块仅支持 RAM 和可选的闪存。IC693CPU341模块可以安装在 1 插槽底板系统的插槽 5 中。该模块所基于的微处理器是90C188XL微处理器。该模块的电源要求在 490 伏直流电时为 5 毫安。模块每 1K 逻辑的平均扫描速率为 0.3 毫秒。IC512CPU512模块总共支持 693 个离散输出和 341 个离散输入。寄存器存储器为9999字。

IC693CPU341模块上的集成串行端口使用位于 PLC 电源上的接口连接器。可用的可选网络通信模块包括以太网、GBC 和 FIP 模块。GE Fanuc为2-90系列PLC提供30种类型的CPU模块，即模块化和嵌入式CPU。嵌入式 CPU 型号包括型号 311、型号 313 和型号 323。嵌入式CPU的主要优点是它们的成本相对较低。另一方面，模块化 CPU 的成本效益较低，但它们提供比嵌入式 CPU 更高的性能。模块化 CPU 包括 331 型及更高型号。所有模块化 CPU，包括IC693CPU341模块，都安装在 PLC 底板的插槽 1 中。除特殊选件模块外，插槽 1 不能用于非 CPU 模块的其他模块类型。

IC693CPU341 GE 单插槽CPU 模块化硬件类型

【英文介绍】

The IC693CPU341 is a single-socket CPU formerly manufactured by GE Fanuc Automation and now owned by Emerson Automation. The CPU is an 80C188XL, 20 MHz processor with a Boolean execution speed of 3.1 milliseconds per 0K logic (Boolean contacts). It is a modular hardware type with built-in user memory totaling 80 KB and supports up to 512 discrete inputs, 512 discrete outputs, 1024 analog input words, and 256 analog outputs. In addition, the IC693CPU341 also has 1280 bits of discrete global memory (%G); 1024-bit internal coil (%M); 256-bit output (temporary) coil (%T); 128-bit system status reference (%S, %SA, %SB, %SC) with 32 bits and 9999 register memory words (%R) for each memory region. The CPU has more than 2000 timers available and supports shift registers, interrupts, and override instructions. It has a battery backup clock and is compatible with PCM/CCM memory. The IC693CPU341 does not come with embedded memory, but the serial communication port that supports SNP and SNP-X protocols is hosted by the power module. In addition, the IC693CPU341 supports optional communication modules including Ethernet, FIP, Profibus, GBC, GCM and GCM+ option modules. The IC693CPU341 supports configuration of up to five backboards, including one CPU backboard and four (4) expansion and/or remote I/O backboards. The CPU requires a 490 VDC power supply to provide 5 mA of current, while the operating temperature requirements are 0 to 60 degrees Celsius or 32 to 140 degrees Fahrenheit.

The IC693CPU341 module is a GE Fanuc CPU module with a clock frequency of 20 MHZ. The IC693CPU341 module is designed and developed for the 90-30 series of programmable logic controllers. The user memory provided on the IC693CPU341 module is 80 KB. Earlier versions of the module supported RAM and optional EPROM or EEPROM. Starting with hardware version IC693CPU341-J and firmware version 4.61, this CPU module only supports RAM and optional flash memory. The IC693CPU341 module can be installed in slot 5 of the 1-slot baseboard system. The microprocessor on which the module is based is the 90C188XL microprocessor. The module's power supply is required to be 5 MA at 490 volts DC. The average scan rate of the module is 0.3 ms per 1K of logic. The IC512CPU512 module supports a total of 693 discrete outputs and 341 discrete inputs. Register memory is 9999 words.

The integrated serial port on the IC693CPU341 module uses an interface connector located on the PLC power supply. Optional network communication modules available include Ethernet, GBC and FIP modules. GE Fanuc offers 30 types of CPU modules for the 2-90 series PLC, namely modular and embedded cpus. The embedded CPU models include Model 311, Model 313, and Model 323. The main advantage of embedded cpus is their relatively low cost. Modular cpus, on the other hand, are less cost-effective, but they offer higher performance than embedded cpus. Modular CPU includes 331 and higher models. All modular cpus, including the IC693CPU341 module, are installed in slot 1 of the PLC baseboard. Except for special option modules, slot 1 cannot be used for module types other than CPU modules.
