IC693CPU323 GE 带有嵌入式涡轮增压CPU的底板

【产品详情】

IC693CPU323是由GE Fanuc制造的90-30系列组件。具体来说，这是一个带有嵌入式涡轮增压CPU的底板。这是专门为小型应用设计的，因为IC693CPU323不支持扩展，也不支持PCM和CCM模块等高级模块。

该IC693CPU323有一个被归类为涡轮增压CPU的CPU，其典型扫描速率为每0K布尔逻辑6.1毫秒。它加载了 12KB 的用户内存，对于版本 6 之前的版本，最大或 7KB。它支持多达 320 个离散 I/O 点;64字模拟输入和32字模拟输出字。该IC693CPU323配有340个定时器和计数器，并支持移位寄存器指令。

用于IC693CPU323的处理器是时钟速度为 80188 MHz 的 10 MHz。它还提供了支持SNP从机和SNP-X从站协议的串行接口。它还支持安装可选通信功能，包括以太网、FIP、Profibus、GBC、GCM、GCM+ 选件模块。

除了作为不可扩展的硬件外，IC693CPU323不支持超控功能、电池备份时钟和程序中断。默认情况下，它使用电池备份的RAM，但是，电池实际上由电源模块托管。它也可以与可选的非易失性存储器一起安装，例如EPROM和EEPROM。

IC693CPU323支持面板安装，通过底板上提供的安装孔固定。该装置的电流负载为430 mA，采用+5VDC电源供电。

IC693CPU323底板是GE Fanuc系列90-30 Ten插槽嵌入式CPU底板。嵌入式 CPU 具有低成本的优势，但它们缺乏模块化 CPU 的强大功能和多功能性。嵌入式CPU是嵌入式CPU基板的一部分，其中CPU和内存芯片焊接在基板的背板上。嵌入式 CPU 无法更改，它们不支持扩展或远程机架，并且它们没有时间时钟，因为内存备用电池位于电源电源中，拔下电源会导致电池与内存电路断开连接，这会干扰时间时钟的设置。

IC693CPU323底板的功率要求是 5 伏直流电压和 430 毫安电流。IC693CPU323底板与 PCM 和 CCM 器件不兼容。该模块的工作温度范围为 0 至 60 摄氏度。中断、覆盖和电池备份时钟是IC693CPU323底板上没有的功能。支持移位寄存器。可用的一个或多个计时器和计数器为 340。IC693CPU323基板上的单个串行端口仅支持SNP从机和SNP-X从机通信协议。如果需要，可以单独订购Profibus、以太网和GCM协议的可选模块。模拟输入总共分配了 64 个字，模拟输出分配了 32 个字。IC693CPU323底板总共支持 320 个组合的离散输入和输出。

IC693CPU323 GE 带有嵌入式涡轮增压CPU的底板

【英文介绍】

The IC693CPU323 is a 90-30 series component manufactured by GE Fanuc. Specifically, this is a baseboard with an embedded turbocharged CPU. This is specifically designed for small applications, as the IC693CPU323 does not support extensions, nor does it support advanced modules such as PCM and CCM modules.

The IC693CPU323 has a CPU classified as a turbocharged CPU with a typical scan rate of 6.1 milliseconds per 0K Boolean logic. It loads 12KB of user memory, with a maximum or 7KB for versions prior to version 6. It supports up to 320 discrete I/O points; 64 word analog input and 32 word analog output. The IC693CPU323 is equipped with 340 timers and counters and supports shift register instructions.

The processor for the IC693CPU323 is 10 MHz with a clock speed of 80188 MHz. It also provides a serial interface that supports the SNP slave and SNP-X slave protocols. It also supports the installation of optional communication features, including Ethernet, FIP, Profibus, GBC, GCM, GCM+ option modules.

In addition to being non-scalable hardware, the IC693CPU323 does not support override features, battery backup clock, and program interrupts. By default, it uses battery backup RAM, however, the battery is actually hosted by the PSU. It can also be installed with optional non-volatile memory such as EPROM and EEPROM.

The IC693CPU323 supports panel installation and is secured through the mounting holes provided on the mainboard. The unit has a current load of 430 mA and is powered by a +5VDC supply.

The IC693CPU323 mainboard is a GE Fanuc series 90-30 Ten slot embedded CPU mainboard. Embedded cpus have the advantage of low cost, but they lack the power and versatility of modular cpus. An embedded CPU is a part of an embedded CPU substrate in which the CPU and memory chip are soldered to the backplane of the substrate. Embedded cpus cannot be changed, they do not support expansion or remote racks, and they do not have a time clock because the memory backup battery is located in the power supply, and unplugged the power will cause the battery to disconnect from the memory circuit, which will interfere with the setting of the time clock.

The power requirements of the IC693CPU323 baseplate are 5 volts DC and 430 mA. The IC693CPU323 baseboard is not compatible with PCM and CCM devices. The module operates in a temperature range of 0 to 60 degrees Celsius. Interrupt, overlay, and battery backup clock are features not available on the IC693CPU323 mainboard. Supports shift registers. One or more timers and counters are available for 340. The single serial port on the IC693CPU323 substrate supports only SNP slave and SNP-X slave communication protocols. Optional modules for Profibus, Ethernet and GCM protocols can be ordered separately if required. The analog input was assigned a total of 64 words, and the analog output was assigned 32 words. The IC693CPU323 baseboard supports a total of 320 combined discrete inputs and outputs.
