IC693CPU321 插槽I/O底板 GE  带有嵌入式CPU

【产品详情】

GE Fanuc IC693CPU321 CPU底板是一个10插槽I/O底板，带有嵌入式CPU，用于90-30系列PLC系统。IC693CPU321底板属于90-30系列嵌入式CPU底板系列，旨在提供低成本的PLC安装解决方案。IC693CPU321 CPU基板由CPU和集成存储器电路芯片（RAM、EPROM和EEPROM）组成，它们都牢固地焊接在底板的背板电路上。IC693CPU321 CPU 底板不附带扩展连接器，因此不支持使用扩展或远程机架。它的最大 I/O 容量为 10 个 I/O，不适合需要 10 个以上 I/O 模块的应用和系统。IC693CPU321底板配有一个 10 兆赫兹 80188 微处理器，可提供操作控制，并以毫秒/千比特 （ms/K） 的执行速度执行所有非布尔函数

IC693CPU321 CPU 底板最多支持 320 个离散输入和 320 个离散输出，或 64 个模拟输入和 32 个模拟输出。IC693CPU321 CPU底板上在电源上具有1个内置RS-485 15针D型母连接器端口，用于连接到运行GE Fanuc Windows的PLC编程软件的个人计算机，GE Fanuc手持编程器和其他串行设备。它还支持其他通信选项，如串行SNP，RTU，LAN-Genius，Ethernet SRTP，Ethernet Modbus TCP，Profibus-DP和DeviceNet模块。IC693CPU321底板通过使用基于 DOS 的 LogicMaster、基于 Windows 的 Versa-Pro 和 Proficy Logic Developer （Machine Edition） 软件支持软件配置。IC693CPU321 CPU 底板具有电池备份的 12 KB 用户逻辑存储器，用于应用存储，在 430 V 直流电下的最大背板电流消耗为 5 毫安。

IC693CPU321 插槽I/O底板 GE  带有嵌入式CPU

【英文介绍】

GE Fanuc IC693CPU321 CPU backboard is a 10-slot I/O backboard with an embedded CPU for 90-30 series PLC systems. The IC693CPU321 backboard belongs to the 90-30 series of embedded CPU backboards designed to provide a low cost PLC installation solution. The IC693CPU321 CPU substrate consists of the CPU and integrated memory circuit chips (RAM, EPROM, and EEPROM), which are solidly welded to the backplane circuit of the backplane. The IC693CPU321 CPU baseboard does not come with an expansion connector, so the use of expansion or remote racks is not supported. With a maximum I/O capacity of 10 I/ OS, it is not suitable for applications and systems that require more than 10 I/O modules. The IC693CPU321 backboard is equipped with a 10 MHZ 80188 microprocessor that provides operational control and performs all non-Boolean functions at an execution speed of ms/ kilobit (ms/K)

The IC693CPU321 CPU backboard supports up to 320 discrete inputs and 320 discrete outputs, or 64 analog inputs and 32 analog outputs. The IC693CPU321 CPU baseboard has a built-in RS-485 15-pin type D female connector port on the power supply for connecting to personal computers running GE Fanuc Windows PLC programming software, GE Fanuc handheld programmers and other serial devices. It also supports other communication options such as Serial SNP, RTU, LAN-Genius, Ethernet SRTP, Ethernet Modbus TCP, Profibus-DP and DeviceNet modules. The IC693CPU321 baseboard supports software configuration by using DOS-based LogicMaster, Windows-based Versa-Pro, and Proficy Logic Developer (Machine Edition) software. The IC693CPU321 CPU backboard has 12 KB of user logic memory with battery backup for application storage and a maximum backplane current consumption of 5 mah at 430 V DC.

IC693CPU321 插槽I/O底板 GE  带有嵌入式CPU
