531X207LCSACG1  局域网电流源板 LCS 531X 板系列

【产品详情】

通用电气 531X207LCSACG1 是一款局域网 （LAN） 电流源板。此可选卡是 531X 系列更换和可选主板的成员。GE品牌的许多驱动器和励磁器都可以接受并使用此LAN电流源板。该卡从保险丝保护的 115 VAC 输入电源获取电源。上电时，该板提供 5 VDC 或 15 VDC 的额定电源以及电压限制为 0.3 A 的电流源。

安装后，531X207LCSACG1 为其驱动器的 LAN 板提供电流源。5 VDC 和 15 VDC 均可通过该板供电，具体取决于用户选择。板上的跳线 （JP1） 允许用户选择电源，位置 1.2 允许 5 VDC，位置 2.3 允许 15 VDC。板载电位计 （P1） 允许用户调整这些电源产生的输出电压。该卡还包括一个受保护的保险丝和一个端子板。电路板的输入和从电路板发送的输出都通过 12 点端子板传输。

应满足任何提供的安装参数，以保护电路板的完整性。只有经过培训且在操作驱动板方面经验丰富的合格人员才能安装 531X207LCSACG1。 有关如何正确连接 LAN 电流源板的说明，请使用器件数据表和手册中的插图说明。 531X 系列的电路板最初由制造商通用电气提供技术支持。

531X207LCSACG1  局域网电流源板 LCS 531X 板系列

【英文介绍】

The GE 531X207LCSACG1 is a local area network (LAN) current source board. This optional card is a member of the 531X series replacement and optional motherboards. Many GE branded drives and exciters can accept and use this LAN current source board. The card draws power from a fusion-protected 115 VAC input. When powered on, the board provides A rated power supply of 5 VDC or 15 VDC and a current source with a voltage limit of 0.3 A.

Once installed, the 531X207LCSACG1 provides a current source to the LAN board of its driver. Both 5 VDC and 15 VDC power can be supplied through the board, depending on the user's choice. The jumper on the board (JP1) allows the user to select the power supply, allowing 5 VDC at position 1.2 and 15 VDC at position 2.3. The onboard potentiometer (P1) allows the user to adjust the output voltage generated by these power supplies. The card also includes a protected fuse and a terminal board. Both the input to the board and the output sent from the board are transmitted through the 12-point terminal board.

Any installation parameters provided should be met to protect the integrity of the board. Only qualified personnel who are trained and experienced in operating the driver board can install the 531X207LCSACG1. For instructions on how to properly connect a LAN current source board, use the illustrations in the device data sheet and manual. The board for the 531X series was initially supported by manufacturer General Electric.
