531X196DFAACG1 GE数字现场辅助板 PCB板组件

【产品详情】

531X196DFAACG1是GE作为531x系列板的一部分创建的PCB板组件。 531x系列PCB不是连接到特定的驱动器系列，而是可用于通用电气制造的一些通用驱动系统。这包括 DC-300 驱动器。您的用户指南或手册将有助于确定兼容性。

531X196DFAACG1用作数字现场辅助板。 PCB由许多组件组成，包括其中心带有四根表面导线的变压器组件。这些电线（两根红色和两根白色）在标记为 R1、R2、W1 和 W2 的点连接到电路板。该板使用额外的表面布线来连接电容器和金属膜电阻器，两者都位于左上角。

531X196DFAACG1 在电路板的每个角落钻孔以进行安装。它有一个 31 针接头连接器，以及五个卡入式连接器。 卡入式连接器位于与右边缘平行的单行中。它们被标记为 VG（红色）、VC（白色）、VM（蓝色）、IP（红色）和 IN（白色）。该板标有代码F196X1DFAAAG<>。

531X196DFAACG1 表面的其他组件包括两个电位计、四个跳线开关、陶瓷和电解电容器、金属膜电阻器和四个集成电路，包括高性能模拟比较器、高性能模拟功率双极晶体管和高性能模拟运算放大器。如果需要有关组件或电路板功能、安装或使用的更多信息，请参阅制造商手册、数据表或用户指南。这些出版物还将提供建议的处理程序。

531X196DFAACG1 GE数字现场辅助板 PCB板组件

【英文介绍】

The 531X196DFAACG1 is a PCB board component created by GE as part of the 531x series board. The 531x series PCB is not connected to a specific driver family, but can be used in some general purpose drive systems manufactured by General Electric. This includes DC-300 drives. Your user guide or manual will help determine compatibility.

The 531X196DFAACG1 is used as a digital field assist board. A PCB consists of a number of components, including a transformer assembly with four surface wires in its center. These wires (two red and two white) connect to the board at points labeled R1, R2, W1, and W2. The board uses additional surface wiring to connect capacitors and metal film resistors, both located in the upper left corner.

531X196DFAACG1 Drill holes in each corner of the board for installation. It has a 31-pin connector, as well as five snap-in connectors. The snap-in connector is located in a single row parallel to the right edge. They are labeled VG (red), VC (white), VM (blue), IP (red), and IN (white). The board is labeled with the code F196X1DFAAAG<>.

Other components on the surface of the 531X196DFAACG1 include two potentiometers, four jumper switches, ceramic and electrolytic capacitors, metal film resistors, and four integrated circuits, including a high-performance analog comparator, a high-performance analog power bipolar transistor, and a high-performance analog operational amplifier. If you need more information about component or board function, installation, or use, refer to the manufacturer's manual, data sheet, or user guide. These publications will also provide recommended processing procedures.

531X196DFAACG1 GE数字现场辅助板 PCB板组件
