531X191RTBAKG3 继电器端子板 许多集成功能

【产品详情】

通用电气制造了531X191RTBAKG3卡，用作继电器端子板。该设备是作为 531X 系列替换驱动板的成员开发的。由于它用作替换板，因此许多旧型号的GE驱动器可以将此卡安装在其驱动器柜中。安装此卡时，主机驱动器具有两个功能。继电器端子板为驱动器提供板上的七个继电器触点，以及直接访问板载触点和线圈。

该继电器端子板上有许多集成功能。安装 531X191RTBAKG3 板可为已安装的驱动器提供七个继电器点。连接到电路板的外部电路可以使用这些继电器进行控制。它还可以对RTB点和继电器触点进行制表。所有线圈和触点额定值都是为 G3 版本的电路板开发的。每个继电器包含一个线圈，其额定电压为 115 VAC，频率速率为 50/60 Hz。继电器内的触点额定电流为 2.4 A，额定电压为 28 VDC 或 125 VAC。该板的浪涌电流上限为 25 mA，而保持电流的额定电流为 14 mA。

主板完整性依赖于用户查看并遵循提供的任何安装参数。 由于该设备是敏感设备，因此 531X191RTBAKG3 只能由经过培训的人员安装，以处理驱动板。请务必仔细阅读所有安装和接线说明。 设备手册和数据表中提供了该继电器端子板的综合接线指南。 该板的技术支持最初由制造商通用电气提供。

531X191RTBAKG3 继电器端子板 许多集成功能

【英文介绍】

Ge manufactured the 531X191RTBAKG3 card for use as a relay terminal board. The device was developed as a member of the 531X series replacement driver board. Since it serves as a replacement board, many older models of GE drives can have this card installed in their drive cabinets. When this card is installed, the host drive has two functions. The relay terminal board provides the driver with seven relay contacts on the board, as well as direct access to on-board contacts and coils.

There are many integrated functions on the relay terminal board. Installing the 531X191RTBAKG3 board provides seven relay points for the installed drive. External circuits connected to the board can be controlled using these relays. It can also tabulate RTB points and relay contacts. All coil and contact ratings were developed for the G3 version of the board. Each relay contains a coil with a rated voltage of 115 VAC and a frequency rate of 50/60 Hz. The contacts in the relay are rated for 2.4A current and rated for 28 VDC or 125 VAC. The board has a maximum surge current of 25 mA, while the holding current is rated at 14 mA.

Motherboard integrity depends on the user viewing and following any installation parameters provided. Because the device is sensitive, the 531X191RTBAKG3 should only be installed by trained personnel to handle the driver board. Be sure to read all installation and wiring instructions carefully. A comprehensive wiring guide for the relay terminal board is provided in the equipment manual and data sheet. Technical support for the board was initially provided by manufacturer General Electric.
