531X191RTBAHG4 中继端子板 提供了许多功能

【产品详情】

通用电气将531X191RTBAHG4卡设计为中继端子板。作为531X系列替换驱动和励磁板的产品，该卡可以安装在许多产品中。GE 系列上的驱动器可以将此卡安装在其驱动器机柜中。此驱动器为其已安装的驱动器提供两项服务。包括七个板载继电器，以及通过卡的端子板访问线圈和触点。

531X191RTBAHG4 继电器端子板为其已安装的驱动器提供了许多功能。七个继电器中的每一个都包括一个 24 VDC 线圈。 这些继电器内的触点电流为 37 mA，电流为 2.4 A。该卡的电压额定值为 125 VAC 或 28 VDC，每 1.0 V 1 mA 电流。该卡还具有将RTB点和继电器触点制成表格的技术。每个继电器都配有一个 LED 指示灯。当继电器通电时，它们将亮起，以直观地向用户指示它们已通电。可以使用该板控制任何有线外部电路。

用户应满足制造商提供的安装参数。 提供这些是为了帮助用户降低设备损坏或用户受伤的风险。由于它是敏感的电路，因此此卡只能由经过培训的驱动器组件的人员安装。该卡的完整接线指南可在设备手册和数据表中找到。通用电气最初为531X191RTBAHG4继电器端子板提供技术支持。

531X191RTBAHG4 中继端子板 提供了许多功能

【英文介绍】

Ge designed the 531X191RTBAHG4 card as a relay terminal board. As a replacement driver and exciter for the 531X series, the card can be installed in many products. Drives on the GE series can install the card in their drive cabinets. This drive provides two services for its installed drives. Includes seven on-board relays, as well as access to coils and contacts through the card's terminal plate.

The 531X191RTBAHG4 relay terminal board provides many features for its installed drivers. Each of the seven relays includes a 24 VDC coil. The contact current within these relays is 37 mA and the current is 2.4 A. The card has a voltage rating of 125 VAC or 28 VDC with 1 mA current per 1.0 V. The card also has technology for tabulating RTB points and relay contacts. Each relay is equipped with an LED indicator. When the relays are powered on, they light up to visually indicate to the user that they are powered on. The board can be used to control any wired external circuit.

The user shall meet the installation parameters provided by the manufacturer. These are provided to help users reduce the risk of equipment damage or user injury. Because it is a sensitive circuit, this card can only be installed by a person trained in driver components. Complete wiring guidelines for the card can be found in the device manual and data sheet. Ge initially provided technical support for the 531X191RTBAHG4 relay terminal board.

531X191RTBAHG4 中继端子板 提供了许多功能
