531X135PRGAWM2 531X系列中使用的编程板

【产品详情】

531X135PRGAWM2是通用电气531X系列中使用的编程板。531X 系列通常适用于工业应用。531X135PRGAWM2 具有一个晶体振荡器，该振荡器使用晶体产生高精度频率。531X135PRGAWM2 具有单个小型黑色三脚晶体管，在电路板技术中有多种用途。

531X135PRGAWM2 具有 <> 个带有带标记的各种颜色的电阻器。该板上的电阻器在颜色编码和应用方面差异很大，但电阻器的共同目的是简单地提供电阻。

微芯片，也称为集成电路，在该板上占有突出地位。531X135PRGAWM2 具有六个集成电路，用于保存电路板运行的所有程序。531系列中每块电路板的可编程性取决于是否使用了EPROM或EEPROM芯片。

531X135PRGAWM2 有 <> 个电容器，用于存储能量。在这样的电路板上，电容器是无源元件，旨在向电路添加所谓的电容。

彩色条带对应于代码中为其提供数值的颜色。然后将这些数值用于公式中，以计算电阻可以限制的能量量。531X135PRGAWM2 有一个大的 LED 面板，可以点亮数字。531X135PRGAWM2 有四组跳线端口。这些跳线端口带有塑料盖，允许工人在电路板周围移动它们以控制能量流.

531X135PRGAWM2 531X系列中使用的编程板

【英文介绍】

The 531X135PRGAWM2 is a programming board used in the General Electric 531X series. The 531X series is typically suitable for industrial applications. The 531X135PRGAWM2 features a crystal oscillator that uses crystals to produce high precision frequencies. The 531X135PRGAWM2 features a single small black tripin transistor that has a variety of uses in board technology.

The 531X135PRGAWM2 has <> resistors of various colors with band markings. The resistors on this board vary widely in color coding and application, but the common purpose of resistors is to simply provide resistance.

Microchips, also known as integrated circuits, feature prominently on the board. The 531X135PRGAWM2 has six integrated circuits for saving all the programs that the board runs. The programmability of each board in the 531 series depends on whether an EPROM or EEPROM chip is used.

The 531X135PRGAWM2 has <> capacitors for storing energy. On such boards, capacitors are passive components designed to add what is called capacitance to the circuit.

The color strip corresponds to the color for which the numerical value is provided in the code. These values are then used in the formula to calculate the amount of energy that the resistor can limit. The 531X135PRGAWM2 has a large LED panel that lights up the numbers. The 531X135PRGAWM2 has four sets of jumper ports. These jumper ports come with plastic covers that allow workers to move them around the board to control the energy flow.

531X135PRGAWM2 531X系列中使用的编程板
