DS200SIOBH1ACA  I/O控制板 每个块中有6个开关

【产品详情】

GE I/O控制板DS200SIOBH1ACA具有20个跳线和3个开关块，每个块中有6个开关，总共18个开关。它还配备了一个LED和一个40针连接器。原始板上的GE I/O控制板DS200SIOBH1ACA上的跳线带有出厂默认设置的跳线。在安装电路板之前，您可以查看印刷材料中的信息，了解跳线的备选设置以及它们如何改变电路板的操作。有些跳线只有一个支撑位置，因此不能改变。

当您发现必须更换单板时，最好的做法是将新单板上的跳线设置为与旧单板上的跳线位置相匹配。通过这种方式，董事会将采取相同的行动并支持驱动器性能。首先通过移除将其固定在板架上的螺钉来移除旧板，然后用两只手将板从驱动器上移除。小心不要让电路板碰到驱动器中的其他组件。在附近找一个干净干燥的表面，铺平防静电袋。把旧木板放在袋子上。打开装单板的密封保护袋，将单板滑出。用两只手拿着它，把它放在旧板旁边。将开关设置为与旧单板上的开关位置匹配。

DS200SIOBH1ACA  I/O控制板 每个块中有6个开关

【英文介绍】

The GE I/O control board DS200SIOBH1ACA has 20 jumpers and 3 switch blocks with 6 switches in each block for a total of 18 switches. It also comes with an LED and a 40-pin connector. The jumpers on the GE I/O control board DS200SIOBH1ACA on the original board come with the factory default Settings of the jumpers. Before installing the board, you can review the information in the printed material to learn about alternative Settings for jumpers and how they change the operation of the board. Some jumpers have only one support position and therefore cannot be changed.

When you find that you have to replace a board, the best thing to do is set the jumper on the new board to match the jumper position on the old board. In this way, the board will take the same action and support drive performance. The old board is first removed by removing the screws that hold it to the board frame, and then the board is removed from the drive with two hands. Be careful not to let the board touch other components in the drive. Find a clean, dry surface nearby and lay out an anti-static bag. Put the old board on the bag. Open the protective bag of the board and slide the board out. Hold it in both hands and place it next to the old board. Set the switch to match the switch position on the old board.
