IC660CBB902 总线控制器 接口模块

【产品详情】

GE Fanuc IC660CBB902系列6总线控制器是一款系列6 PLC总线控制器。该设备将6系列PLC连接到Genius I/O串行总线。一条Genius I/O串行总线最多可以容纳31个I/O设备，包括Genius I/O块、接口模块和手持显示器。它还支持广泛的Genius I/O块，它可以用于6系列PLC和连接在总线上的Genius I/O设备之间的配置通信。IC660CBB902总线控制器属于B相增强型总线控制器系列。它适用于使用153.6千波特标准速率以外的任何波特率的总线，最大连接距离小于2000英尺。IC660CBB902总线控制器还兼容具有电阻温度检测器(rtd)块或具有64个以上I/O位的Genius I/O块的总线，具有CPU到CPU通信的系列6 PLC系统以及具有总线冗余的系统。

GE Fanuc IC660CBB902总线控制器具有内置诊断功能，可自动从总线上的Genius I/O块向CPU发送诊断报告。IC660CBB902总线控制器可以安装在系列6 CPU的任意I/O槽位上，也可以安装在普通I/O机架或大容量I/O机架上，也可以安装在远程I/O机架上(但不推荐安装)。IC660CBB902总线控制器有两个LED状态指示灯(“BOARD OK”LED和“COMM OK”LED)和一个手持式监视器连接器，用于访问安装在总线上的所有设备。IC660CBB902总线控制器也有4个上端子串行总线连接和低连接器跳线(JP1, JP2和JP3)的天才I/O总线的终端。

IC660CBB902 总线控制器 接口模块

【英文介绍】

GE Fanuc IC660CBB902 Series 6 Bus controller is a series 6 PLC bus controller. The device connects the 6 series PLC to the Genius I/O serial bus. A single Genius I/O serial bus can accommodate up to 31 I/O devices, including Genius I/O blocks, interface modules, and handheld displays. It also supports a wide range of Genius I/O blocks, which can be used for configuration communication between 6-series PLCS and Genius I/O devices connected on the bus. The IC660CBB902 bus controller belongs to the B-phase enhanced bus controller family. It is suitable for buses using any baud rate other than the 153.6 kilobit standard rate, with a maximum connection distance of less than 2000 feet. The IC660CBB902 bus controller is also compatible with buses with Resistance temperature detector (rtd) blocks or Genius I/O blocks with more than 64 I/O bits, Series 6 PLC systems with CPU-to-CPU communication, and systems with bus redundancy.

The GE Fanuc IC660CBB902 bus controller has a built-in diagnostic function that automatically sends diagnostic reports to the CPU from the Genius I/O block on the bus. The IC660CBB902 bus controller can be installed in any I/O slot of the Series 6 CPU, in an ordinary I/O rack, in a high-capacity I/O rack, or in a remote I/O rack (though installation is not recommended). The IC660CBB902 bus controller has two LED status indicators (" BOARD OK "LED and" COMM OK "LED) and a handheld monitor connector for access to all devices mounted on the bus. The IC660CBB902 bus controller also has 4 upper terminals for serial bus connections and low connector jumpers (JP1, JP2 and JP3) for genius I/O bus terminals.

IC660CBB902 总线控制器 接口模块
