IC660BRD021  I/O模块 固态和机电型传感器

【产品详情】

IC660BRD021 I/O模块是GE Fanuc 24或48伏直流额定sink I/O模块。IC660BRD021 I/O模块的应用包括与固态和机电型传感器一起使用。IC660BRD021 I/O模块是一个16路I/O模块。使用24伏直流电源，当直流电压在0到8伏之间时，输入接通，当直流电压在17到24伏之间时，输入断开。使用48v直流电源时，直流电压在0 ~ 16v之间时输入导通，直流电压在34 ~ 48v之间时输入关断。典型的输入阻抗在24伏和48伏直流电时为5.6千欧姆，在24伏直流电时为1.8千欧姆。典型的输入处理时间为1.7毫秒，加上可选择的滤波器延迟时间。

IC660BRD021 I/O块支持多种输入诊断，包括断线诊断、过温诊断和开关故障诊断。IC660BRD021 I/O模块有16个电路，每个电路可以配置为输出、输入或三态输入。控制电源来自连接到终端的I/O设备。不需要单独的电源块。推荐的储存和使用温度范围分别为-40 ~ 100摄氏度和0 ~ 60摄氏度。IC660BRD021 I/O块的振动等级为5至10赫兹或10至200赫兹。IC660BRD021 I/O块与任何手持监视器兼容。IC660BRD021 I/O块为开放式设备，需要安装在保护框内。安装砌块的区域应没有空气污染物。

IC660BRD021  I/O模块 固态和机电型传感器

【英文介绍】

The IC660BRD021 I/O module is a GE Fanuc 24 or 48 VDC rated sink I/O module. Applications for the IC660BRD021 I/O module include use with solid-state and electromechanical sensors. The IC660BRD021 I/O module is a 16-channel I/O module. With a 24 volt DC power supply, the input is switched on when the DC voltage is between 0 and 8 volts, and disconnected when the DC voltage is between 17 and 24 volts. When the 48v DC power supply is used, the input is on when the DC voltage is between 0 and 16v, and the input is off when the DC voltage is between 34 and 48v. The typical input impedance is 5.6 kiloohms at 24 and 48 volts DC and 1.8 kiloohms at 24 volts DC. The typical input processing time is 1.7 ms, plus selectable filter delay time.

The IC660BRD021 I/O block supports multiple input diagnostics, including line break diagnostics, overtemperature diagnostics, and switch fault diagnostics. The IC660BRD021 I/O module has 16 circuits, each of which can be configured as an output, input, or three-state input. The control power comes from an I/O device connected to the terminal. A separate power block is not required. The recommended storage and use temperature ranges are -40 to 100 degrees Celsius and 0 to 60 degrees Celsius, respectively. The IC660BRD021 I/O block has a vibration rating of 5 to 10 Hz or 10 to 200 Hz. The IC660BRD021 I/O block is compatible with any handheld monitor. The IC660BRD021 I/O block is an open device and needs to be installed in the protection enclosure. The area where the blocks are installed should be free of air pollutants.

IC660BRD021  I/O模块 固态和机电型传感器
