IC660BPM500 手持式显示器 电池组

【产品详情】

GE Fanuc IC660BPM500电池组是GE Fanuc手持式显示器(HHM)的电池组，目录号为IC660HHM501。IC660BPM500电池组是发货的一部分，其中包含主机手持监视器。该批货物还包括一个电池充电器(目录号IC660BCM501)和一条连接HHM到I/O块的电缆(目录号IC660HHC005)。IC660BPM500电池组有两个版本:IC660BPM500A版本具有8小时的充电时间，IC660BPM500B版本具有16小时的充电时间。即使HHM使用交流电源，电池组也必须始终安装在HHM中。如果IC660BPM500电池组已完全放电，或者是新的，则必须至少充电20分钟才能操作HHM。HHM是一种操作界面设备，设计用于设置和监控Genius I/O和通信系统。

使用IC660BPM500电池组的HHM的特点包括LCD屏幕，支持多种语言，20键键盘，限制操作员访问的键开关，以及电源选项，包括电池组或115至230伏交流电源。HHM可用于显示连接到总线的设备的I/O数据、诊断、连接到总线的cpu的内存数据、总线扫描时间和全局数据地址。HHM可用于执行故障清除、设备配置、强制I/O电路和双总线选择。HHM极大地简化了系统的一个特点是能够强制模拟和离散I/O。IC660BPM500电池组的工作温度范围为32至140华氏度。储存和运输的推荐温度范围是-40到158华氏度。

IC660BPM500 手持式显示器 电池组

【英文介绍】

The GE Fanuc IC660BPM500 battery pack is a battery pack for the GE Fanuc Handheld Display (HHM), catalog number IC660HHM501. The IC660BPM500 battery pack is part of the shipment, which contains the host handheld monitor. The shipment also includes a battery charger (catalog number IC660BCM501) and a cable connecting the HHM to the I/O block (catalog number IC660HHC005). The IC660BPM500 battery pack is available in two versions: the IC660BPM500A version with an 8-hour charge time, and the IC660BPM500B version with a 16-hour charge time. Even if the HHM uses AC power, the battery pack must always be installed in the HHM. If the IC660BPM500 battery pack is fully discharged, or is new, it must be charged for at least 20 minutes before the HHM can be operated. HHM is an operating interface device designed to set up and monitor Genius I/O and communication systems.

Features of the HHM using the IC660BPM500 battery pack include an LCD screen, support for multiple languages, a 20-key keyboard, a key switch that limits operator access, and power options, including a battery pack or 115 to 230 volt AC power supply. HHM can be used to display I/O data for devices connected to the bus, diagnostics, memory data for cpus connected to the bus, bus scan times, and global data addresses. HHM can be used to perform troubleshooting, device configuration, forced I/O circuits, and dual bus selection. One feature of HHM that greatly simplifies the system is the ability to force simulation and discrete I/O. The IC660BPM500 battery pack operates at a temperature range of 32 to 140 degrees Fahrenheit. The recommended temperature range for storage and transportation is -40 to 158 degrees Fahrenheit.

IC660BPM500 手持式显示器 电池组
